The SB 1223 is used with the SIMATIC S7-1200 platform when additional digital signal capacity is required. Its two 24 V DC inputs can handle binary field signals, while the two 24 V DC transistor outputs provide switching signals for connected automation devices.
Suitable for binary 24 V DC field signals connected to the S7-1200 control system.
Two transistor outputs provide 24 V DC switching capability for connected loads.
The signal board adds digital I/O capacity within the S7-1200 architecture.
In an operating S7-1200 system, this type of signal board may be searched for when digital input states are no longer detected correctly, output switching is unavailable, or the installed board requires replacement during maintenance. Because the board participates directly in field signal handling, an unavailable or defective unit can interrupt the related control functions and may contribute to machine downtime.
AMIKON supports industrial automation supply requirements across 167 countries, serving customers across Europe, the Americas, Asia-Pacific and the Middle East.
It is a SIMATIC S7-1200 SB 1223 digital I/O signal board providing 2 digital inputs and 2 digital outputs, with 24 V DC signal operation.
The board provides 2 digital inputs. The inputs are current-sinking and follow the IEC 61131 Type 1 input characteristic.
The permissible DC supply range is 20.4 V to 28.8 V. For the digital inputs, signal 0 is 0–5 V DC and signal 1 is +15–30 V DC.
It provides 2 digital 24 V DC transistor outputs. The specified output current is up to 0.5 A.
The standard input delay is parameterizable, with selectable values from 0.2 ms through 12.8 ms.
It is commonly searched when an installed SB 1223 requires replacement because digital input or output functions are unavailable, unstable, or affected during maintenance of an S7-1200 control system.
