SIMATIC ET 200SP

Overview Technical Applications FAQ Contact

TECHNOLOGY MODULE

Siemens 6ES7138-6BA01-0BA0

SIMATIC ET 200SP TM PosInput 1

1 Counter 2 DI 2 DQ RS-422 / SSI BU Type A0

CORE FUNCTION

Count &
Position Detection

Designed for position acquisition and counting with RS-422 incremental encoders or SSI absolute encoders in the SIMATIC ET 200SP system.

6ES7138-6BA01-0BA0

PRODUCT SNAPSHOT

Product family	TM PosInput 1
Encoder interface	RS-422 / SSI
Digital inputs	2 DI
Digital outputs	2 DQ
BaseUnit	BU Type A0

TECHNICAL ARCHITECTURE

Built Around Encoder-Based Position Acquisition

Incremental Encoder

Supports RS-422 incremental encoder signals. A/B phase-shifted signals and A/B/N configurations can be evaluated.

Up to 1 MHz input frequency

SSI Absolute Encoder

Supports SSI absolute encoder acquisition through an RS-422 interface with configurable transmission rates.

Clock frequency up to 2 MHz

Digital I/O

Two digital inputs and two digital outputs support technology functions around the counting and position acquisition process.

2 DI + 2 DQ

KEY VALUES

Supply voltage	24 V DC	Counter channels	1
Incremental input frequency	Up to 1 MHz	Quadruple evaluation	Up to 4 MHz
SSI clock frequency	Up to 2 MHz	SSI telegram length	10–40 bit
BaseUnit compatibility	BU Type A0	Net weight	0.049 kg

SYSTEM ROLE

Where the TM PosInput 1 Fits

The module belongs to the SIMATIC ET 200SP technology-module range and is intended for counting and position acquisition from encoder signals. It can be used with RS-422 incremental encoders or SSI absolute encoders, making it suitable for machine axes and processes where position, movement or counting values need to be captured by the control system.

↗

Position Acquisition

Useful when a machine process depends on accurate encoder-based position values.

◌

Counting Tasks

Suitable for high-speed counting applications where encoder pulses must be captured by the automation system.

◇

Encoder Replacement

A practical search target when an existing ET 200SP position module develops encoder, counting or diagnostic faults.

In a running machine, loss of position acquisition can affect motion sequences, counting operations and process synchronization. Selecting the correct replacement module helps reduce unnecessary control-system downtime.

16+ YEARS

Delivering Control System Parts Worldwide

LARGE INVENTORY

Shop Rare & Hard-to-Find Automation Parts

Find What You Need. Keep Your Automation System Moving.

We supply automation parts for ABB, Alstom, Bently Nevada, Emerson, GE, Honeywell, Rolls Entronic, Siemens, Triconex, Westinghouse, and Woodward control systems.

BUYER SEARCH QUESTIONS

6ES7138-6BA01-0BA0 FAQ

Practical questions buyers commonly consider before replacing or integrating the module.

Can I use 6ES7138-6BA01-0BA0 with an RS-422 incremental encoder?

Yes. The module is designed for counting and position acquisition with RS-422 incremental encoders. It supports A/B phase-shifted encoder signals and A/B/N configurations.

What should I check if my application uses an SSI absolute encoder?

Check the encoder interface, telegram length and transmission rate. The TM PosInput 1 supports SSI absolute encoders through RS-422, with configurable telegram lengths from 10 to 40 bits and clock rates up to 2 MHz.

Is 6ES7138-6BA01-0BA0 suitable when high-speed pulse acquisition is required?

It supports incremental encoder input frequencies up to 1 MHz. With quadruple evaluation, the counting frequency can reach up to 4 MHz.

How many digital I/O points are available on this TM PosInput module?

The module provides 2 digital inputs and 2 digital outputs. These I/O points support technology functions associated with counting and position acquisition.

Which BaseUnit should I prepare for 6ES7138-6BA01-0BA0?

The Siemens product specification identifies this TM PosInput 1 as suitable for BU type A0. Confirm the installed BaseUnit configuration before replacing an existing module.

RELATED AUTOMATION MODELS

Explore More Industrial Automation Parts

Selected part numbers
