A compact SIMATIC ET 200SP analog input module with four differential inputs. Each channel can be configured for voltage measurement or current measurement with a 2-wire transducer.
The module combines voltage measurement and 2-wire current measurement in a compact ET 200SP format.
Four analog input channels are available for process signal acquisition.
Supported voltage ranges include ±10 V, ±5 V, 1–5 V and 0–10 V. Current ranges include 0–20 mA and 4–20 mA.
Diagnostic functions include supply monitoring, wire-break detection for 4–20 mA, short-circuit detection, group errors and range errors.
The module is 15 mm wide, 73 mm high and 58 mm deep, with an approximate weight of 31 g.
The 6ES7134-6HD01-0BA1 is intended for analog signal acquisition within the SIMATIC ET 200SP distributed I/O environment. It accepts voltage signals and current signals from 2-wire transducers, making it suitable for process values that need to be transferred into the control system.
During maintenance, this module is typically searched when an existing analog channel becomes unavailable, a process value is no longer transferred correctly, or diagnostic conditions such as wire break, short circuit, supply monitoring, overflow or underflow need to be investigated. A failed analog input can interrupt the controller's access to a process variable and may therefore affect monitoring, regulation or machine operation.
Supply voltage monitoring is available through the module diagnostics.
Wire-break diagnostics are supported for the 4–20 mA measuring range.
Short-circuit monitoring is available for defined voltage and 2-wire configurations.
Overflow and underflow conditions can be monitored by the module.
Shop the largest inventory of rare control system parts. Find what you need for ABB, Alstom, Bently Nevada, Emerson, GE, Honeywell, Rolls Entronic, Siemens, Triconex, Westinghouse and Woodward control systems.
Our range continues to expand as we work to improve the supply of automation components worldwide. Wherever customers are located and however difficult a part may be to locate, our goal is to connect customers with the components required for their automation systems.
For a faster product check, please provide the following details:
Practical questions commonly considered when selecting or replacing this module.
It is a SIMATIC ET 200SP analog input module with four differential inputs. It acquires voltage signals and current signals from 2-wire transducers for use within an ET 200SP automation system.
The module provides four differential analog input channels, with the measuring type selectable per channel.
Yes. Supported voltage ranges include ±10 V, ±5 V, 1–5 V and 0–10 V. Current measurement supports 0–20 mA and 4–20 mA for 2-wire transducers.
The module is designed for BU type A0 and A1 BaseUnits for the 2-wire connection configuration.
Check the selected measuring type and range, sensor wiring, supply conditions and the module diagnostic status. The module supports diagnostics for supply monitoring, wire break on 4–20 mA, defined short-circuit conditions, group errors and overflow or underflow.
