6ES7132-6BH01-0BA0

Overview Specifications Application FAQ Contact

SIMATIC ET 200SP

6ES7132-6BH01-0BA0

Digital Output Module

DQ 16x24VDC/0.5 ST 16 Digital Outputs PNP / Source Output

ET 200SP

OUTPUTS

24 V

0.5 A

/ CHANNEL

CORE CONFIGURATION

Output Capability at a Glance

◉

DIGITAL OUTPUTS

16 Channels

Parameterizable digital outputs

＋

OUTPUT TYPE

PNP / Source

Current-sourcing output design

⚡

LOAD CAPABILITY

0.5 A / Channel

Maximum output current

ELECTRICAL

Rated supply voltage24 V DC

Permitted voltage range19.2–28.8 V DC

Power loss, typical1 W

Reverse polarity protectionYes

DIAGNOSTICS

Supply voltage monitoringYes

Wire break diagnosisYes

Short circuit to L+Yes

Short circuit to groundYes

MECHANICAL

BaseUnitBU type A0

Width15 mm

Height73 mm

Depth58 mm

SYSTEM ROLE

Compact Digital Output Control

The 6ES7132-6BH01-0BA0 belongs to the SIMATIC ET 200SP digital output family. Its 16-channel 24 V DC source outputs are intended for switching connected digital loads within an ET 200SP station.

24 V DC PNP 16 DQ ET 200SP

WHEN REPLACEMENT BECOMES CRITICAL

Output faults can interrupt machine sequences

During troubleshooting, this module may become a replacement target when digital outputs no longer switch the connected loads correctly, when diagnostic conditions indicate wire-break or short-circuit problems, or when the module itself becomes unavailable.

Operational impact: An unavailable output module can affect actuators and downstream machine sequences, potentially extending downtime until the affected I/O function is restored.

BUYER QUESTIONS

6ES7132-6BH01-0BA0 — Practical FAQ

If my ET 200SP station needs 16 digital outputs at 24 V DC, is this module the right output class to investigate?

Yes. The 6ES7132-6BH01-0BA0 provides 16 digital outputs, uses 24 V DC supply/output voltage, and is designed as a PNP current-sourcing output module with a maximum rated output current of 0.5 A per channel.

What should I check before replacing an existing ET 200SP output module with 6ES7132-6BH01-0BA0?

Check the required output count, 24 V DC operating range, PNP/source-output requirement, maximum channel current, and the installed BaseUnit. This model is specified for BU type A0.

A machine output is not responding. Can the module itself help narrow down the fault?

The module provides diagnostic functions including supply-voltage monitoring, wire-break diagnosis, short-circuit diagnosis to L+ and ground, and group-error indication. These functions can help technicians distinguish an I/O-related problem from other machine conditions.

Does the 6ES7132-6BH01-0BA0 support substitute values when an output condition needs a defined fallback state?

Yes. Siemens specifies that substitute values can be enabled for this module. This function is useful when the control application requires a defined output behavior under specified conditions.

How does this 16-channel module compare with an ET 200SP output module having fewer channels?

The main selection difference is channel density. With 16 digital outputs in a 15 mm-wide module, this model is suited to applications where many 24 V DC digital loads must be handled within a compact ET 200SP station.
