Model: MC-4/11/10/400 HW: E0P603 SW:00.22.03
Brand: SCHNEIDER
Warranty:12 months
7/24 online!
WE PROVIDE
●24-hour global logistics network with express courier partners cuts average lead times to <48 h worldwide—no rush fees, no hidden surcharges.
●Every part—new, used, or refurbished—is fully tested and protected by our industry-leading warranty, giving you risk-free operation.
●50+ professionals serve customers in 20+ languages. Custom CRM and real-time order tracking deliver a truly seamless buying experience.
●Aggressive purchasing power + excess-inventory buy-back programs translate into cost savings of up to 30 % versus OEM pricing.
●Authorized distributor for 100+ leading brands; counterfeit-free guarantee through rigorous incoming inspection and supplier audits.
WE ARE HERE FOR YOU
Manager: Miya Zheng
E-mail: sales@amikon.cn
F-WhatsApp/Mobile: 86-18020776792
FEATURES ABOUT MC-4/11/10/400 HW: E0P603 SW:00.22.03
●400 V class, 11 A rms (10 kVA) continuous output for high-dynamic brushless servo motors.
●Integrated “Safe Torque Off” (STO) SIL 3 / PL-e and electronic motor-nameplate memory (via HIPERFACE® or EnDat) for plug-and-play start-up.
●Single-cable Ethernet POWERLINK V2.0 interface on-board; cycle time down to 200 µs for multi-axis synchronisation without additional option cards.
DESCRIPTION
|
Mains supply: 3 × 380 – 480 V AC ±10 %, 48 – 63 Hz; in-rush ≤ 15 A; internal brake-chopper 400 W continuous / 8 kW peak. |
|
Rated DC-bus: 565 – 680 V; bus capacitance 470 µF; braking resistor min. 33 Ω, max. energy 180 kJ. |
|
Output current: 11 A rms continuous, 22 A rms for 3 s (overload 200 %); PWM frequency 4 – 16 kHz (factory 8 kHz). |
|
Peak switching frequency: 16 kHz; current-loop bandwidth 2 kHz; speed-loop update 250 µs. |
|
Protective functions: STO, over-current ±150 %, DC-bus over-voltage 820 V, under-voltage 380 V, phase-loss, I²t motor & amplifier, short-circuit to earth/phase. |
|
Control I/O: 1 × analogue ±10 V (14-bit), 4 × digital 24 V inputs, 2 × digital 24 V outputs, 1 × relay 30 V / 1 A; encoder supply 5 V / 8 V 350 mA. |
|
Ambient: 0 – 45 °C full power (derating 2 %/K to 55 °C max); storage –25 – +70 °C; IP20; weight 2.8 kg; dimensions H × W × D = 300 × 70 × 210 mm. |
