² Overview
The Schneider Electric 140AII33010 is a current input module specifically designed for the Modicon Quantum series. This device accommodates up to 8 inputs and operates within defined current ranges, ensuring broad compatibility.
² Specifications
|
Manufacturer |
Schneider Electric |
|
Product Type |
Current Input Module, Modicon Quantum |
|
Product Line |
Modicon Quantum |
|
Part Number |
140AII33010 |
|
EAN |
3595860025616 |
|
Weight |
2.00 lbs (0.91 kg) |
|
Number of Inputs |
8 |
|
Compatibility |
Modicon Quantum Platform |
|
Input Range |
0-20 mA, 0-25 mA, 4-20 mA |
|
Power Dissipation |
7.5 W |
|
Maximum Input |
25 mA internally limited |
|
Operating Temperature |
0°C to 60°C |
|
Protection Type |
Internal Fuse |
|
Input Impedance |
100 Ohm ± 0.1% |
|
Relative Humidity |
5% to 95% non-condensing |
² Descripution
|
The 140AII33010 module from Schneider Electric is classified as a current input module within the Modicon Quantum series. This component can process 8 separate inputs and is thus suitable for various monitoring and control applications. It functions across an input range, specifically accommodating 0-20 mA, 0-25 mA, and 4-20 mA signals, which enhances its versatility. |
|
With a maximum input of 25 mA that is internally limited, this module effectively safeguards against excess current. Weighing in at just 0.29 kg, it is easy to handle and integrate into existing systems, while its power dissipation of 7.5 W indicates efficient energy use. |
|
The operational temperature range for the 140AII33010 is from 0°C to 60°C, ensuring reliable performance in various environments. This component is equipped with an internal fuse for protection, reducing the risk of damage from electrical faults. It features an input impedance of 100 Ohm ± 0.1%, catering to precise measurements and control. Furthermore, it tolerates relative humidity levels from 5% to 95% without condensation risks, making it suitable for a variety of industrial applications. |
² FAQ
|
Q1. What distinguishes the Schneider 140AII33010 as a dependable discrete input module for Modicon Quantum automation systems? |
|
The Schneider 140AII33010 is a high-density discrete input module designed for the Modicon Quantum platform. It efficiently acquires multiple field input signals, delivering fast and reliable data transmission to the PLC while supporting stable machine control in demanding industrial environments. |
|
Q2. How does the Schneider 140AII33010 improve signal integrity and operational reliability in industrial control applications? |
|
The Schneider 140AII33010 incorporates advanced input circuitry that accurately processes discrete field signals while minimizing the effects of electrical noise and transient disturbances. This helps ensure dependable input recognition, even in electrically demanding production facilities. |
|
Q3. Why is the Schneider 140AII33010 particularly well suited for high-density digital input applications? |
|
With its high channel density, the Schneider 140AII33010 enables engineers to connect numerous digital input devices within a single module, optimizing cabinet space, simplifying wiring architecture, and reducing overall installation complexity in large-scale automation systems. |
|
Q4. Which field devices can be seamlessly integrated with the Schneider 140AII33010 in a PLC-based control system? |
|
The Schneider 140AII33010 is compatible with a broad spectrum of industrial digital input devices, including limit switches, push buttons, proximity sensors, selector switches, photoelectric sensors, relay contacts, and other discrete field instruments commonly used in process and factory automation. |
|
Q5. How does the Schneider 140AII33010 contribute to simplified maintenance and enhanced system diagnostics? |
|
The Schneider 140AII33010 features channel-level status indication that enables maintenance personnel to quickly verify input conditions and identify wiring or field device issues. This diagnostic capability reduces troubleshooting time, improves maintenance efficiency, and helps maximize system uptime. |
