INDUSTRIAL DATA EXCHANGE / 01
PLX32-EIP-MBTCP-UA
EtherNet/IP to Modbus TCP/IP to OPC UA Server Gateway
Connect EtherNet/IP controllers and Modbus TCP/IP equipment through one gateway, while making selected operational data available to OPC UA clients. This three-protocol architecture is useful when control networks and higher-level data applications need a practical exchange point.
|
DATA FLOW / GATEWAY LOGIC
GUI-based configuration · OPC UA user authentication and role-based authorization
|
| 01 / Ethernet | EtherNet/IP and Modbus TCP/IP support data exchange between compatible industrial controllers and networked equipment. The Modbus driver supports multiple client and server connections. |
| 02 / OPC UA | Supports 10 simultaneous OPC UA client connections, with username/password authentication and role-based authorization. Security policies include Basic256Sha256, Basic256 and Basic128Rsa15, subject to configuration compatibility. |
| 03 / Installation | Nominal 24 VDC supply; permitted supply range 10–36 VDC. Operating temperature: −25°C to 70°C. Dimensions (H × W × D): 136.7 × 50.5 × 111.3 mm. |
| MODEL | PRIMARY ROLE | WHEN TO CONSIDER IT |
| PLX32-EIP-MBTCP-UA | EtherNet/IP + Modbus TCP/IP + OPC UA Server | When controller data also needs to be exposed to OPC UA clients. |
| PLX31-MBTCP-MBS4 | Modbus TCP/IP to four-port Modbus serial | When existing serial Modbus equipment must join a TCP/IP network. |
| PLX51-HART-4O | Four-channel HART output connectivity | When HART-compatible field devices such as valve positioners must connect to supported Ethernet protocols. |
|
AMIKON / INDUSTRIAL PARTS SUPPORT
Fast, Reliable Supply for Industrial Automation
AMIKON works to source new and discontinued industrial automation parts for customers across industries. We prioritize responsive communication, dependable order handling and efficient delivery to help customers reduce downtime and keep operations moving.
Our approach is built on quality, reliability, transparent communication and practical support throughout the purchasing process.
|
Sales manager: Miya zheng
✉ EMAIL AMIKON ☎ PHONE / WHATSAPP |
|
OUR TEAM
Responsive Support
Across Borders Clear communication for your parts inquiry.
|
QUALITY FOCUS
Careful Part Handling
Support built around dependable order coordination.
|
WAREHOUSE SUPPORT
Fast, Reliable Delivery
Helping customers reduce avoidable downtime.
|
| Q1. Can PLX32-EIP-MBTCP-UA make controller data available to OPC UA clients? | Yes. Its embedded OPC UA Server provides access to EtherNet/IP and Modbus TCP/IP data, with up to 10 simultaneous OPC UA client connections. Confirm the required tags, addressing and security settings during configuration. |
| Q2. Is PLX32-EIP-MBTCP-UA suitable when only Modbus TCP/IP is required? | It can communicate with Modbus TCP/IP equipment, but the model's main advantage is the combined EtherNet/IP, Modbus TCP/IP and OPC UA role. If the project only needs TCP-to-serial conversion, compare the PLX31-MBTCP-MBS4 instead. |
| Q3. What should be checked before replacing PLX32-EIP-MBTCP-UA? | Check protocol roles, Ethernet addressing, data mapping, OPC UA security requirements, connected client counts, supply voltage and the required operating temperature range. A similar-looking gateway may not support the same three-protocol architecture. |
| Q4. Does PLX32-EIP-MBTCP-UA require a 24 VDC supply? | Its nominal supply is 24 VDC, with an allowed range of 10–36 VDC. Verify the actual panel supply and wiring polarity before commissioning or replacing the unit. |
| Q5. What details help confirm the correct PLX32-EIP-MBTCP-UA for an urgent order? | Provide the complete part number, required quantity, destination, target delivery date and the existing controller/protocol combination. If available, include the installed unit's label and the intended replacement role. |
