Weight 1.00 lbs (0.45 kg) Operating Voltage Range 10 to 30VDC Input Delay Time, OFF to ON 1 ms Input Delay Time, ON to OFF 1 ms or 6 ms Power Dissipation 7.3 Watts (max.), 1.0 Watts (min.)
Weight 0.44 lbs (0.20 kg) Input Voltage 24VD Input Voltage range 10-30VDC ON-state Current, min. 2 mA @ 10V DC ON-state Current, max. 10 mA @ 30V DC Cyclic update time 200 µs…750 ms
Weight 1.00 lbs (0.45 kg) Voltage Range 90-146 Volts DC Sink Inputs 16 Backplane Current (5 Volts DC) 85 milliamps Signal delay 9 milliseconds Off State Current 0.8 milliamps
Input Signal 4 20 mA (2-wire) Measurement Accuracy ±0.1% of span Power Supply Loop-powered (3.8 24 VDC) Operating Pressure Up to 400 bar Operating Temperature -40°C to +85°C Housing Material Stainless steel 316L Protection Rating IP66 / IP67
