GENERAL ELECTRIC WESDAC D20A SBA0009-00 Panel Module

The WESDAC D20A SBA0009-00 Panel Module is an integral component of the GE WESDAC D20A system, designed to handle analog input processing for industrial applications. This module consists of two main parts: the WESTERM D20A, which is responsible for field wiring terminal connections, and the WESDAC D20A, which processes the acquired data and transmits it to the main D20 processor. The WESDAC D20A SBA0009-00 supports up to 32 analog input channels, which can be configured for either voltage or current inputs depending on the application.

• 32 Analog Input Channels: Supports up to 32 analog input channels for flexible configuration.

• Voltage and Current Input Support: Handles both voltage (1, 5, or 10 V) and current inputs via shunt resistors.

• Modular Design: Consists of two parts: WESTERM D20A for terminal connections and WESDAC D20A for data processing

• Real-Time Data Transmission: Facilitates data transfer to the main D20 processor via DB9 connector.

• Power Supply Flexibility: Can be powered by WESDAC D20A input or an external power source
