GE  DS200DTBDG1ABB Terminal Board


 Module Description

DS200DTBDG1ABB Terminal Board

Part Number:  DS200DTBDG1ABB

Series:Mark V

Functional Acronym:DTBD

Mark V Series Grouping:Group 1

Revision Quantity:3 Revisions

Functional Description:Mark V Terminal Board

Dimensions:28.6x7x3.5cm



Funcrional  Description

As with tha vast majority of Mark V Series products available in our new and reconditioned inventory; this

 DS200DTBDG1ABB product offering is accompanied by its own set of functionality-introducing hardware

component inclusions, specifications, and installation procedures.The GE Terminal Board DS200DTBDG1ABB

features 2 terminal blocks. Each block contains 107 terminals for signal wires. The GE Terminal Board

DS200DTBDG1ABB also contains multiple test points, 2 jumpers, and 3 34-pin connectors. The board

also contains 3 40-pin connectors. In addition to some of its more-specialized hardware component

inclusions and specifications, this DS200DTBDG1ABB PCB is also populated by many standard

Mark V Series voltage-limiting hardware components, such as rectifiers, diodes, and capacitors,

and is additionally coated by a thick rudimentary protective layer of normal-style PCB coating.

The board is 11.25 inches in length and 3 inches in height. It is designed to fit in a specific

location in the drive interior and is secured in place with screws. The connectors available to

the assembly of this DS200DTBDG1ABB product offering include:

The JS1-JS8 TCRA Board Relay Signal Connectors

The J8 TCPD Board Solenoid Power Connector

The J19 and J20 Daisy-Chained Contact Outputs Power Connectors





Email :sales@amikon.cn

Skype :miyazheng520

Phone/WhatsApp : 86-18020776792

Frequently  Asked Questions About  DS200DTBDG1ABB



What is the DS200DTBDG1ABB Terminal Board?

The DS200DTBDG1ABB Terminal Board is an interface component used in industrial control systems. It provides a connection point for wiring various signals and power sources to the control system.

How is the DS200DTBDG1ABB Terminal Board installed?
The terminal board is mounted in a compatible control panel or rack. Connect the appropriate cables to the terminals according to the wiring diagram provided in the installation manual.
What maintenance does the DS200DTBDG1ABB Terminal Board require?

Regular maintenance includes inspecting connections for signs of wear or damage and ensuring the board is clean and free from debris. Periodically check the integrity of the wiring connections.
