| Key Specifications | |
| Types A - D, and Type E in Up/Down mode | 200 KHz |
| Type E in A Quad B mode | 800 KHz |
| Output Points | Powered by user supplied 5V, or 10 to 30 VDC |
| Peak (1 second) | 1500 volts |
| Steady Status | 30 V AC/DC |
| Voltage Range | 5 VDC |
| Non-TTL | 10 to 30 VDC |
| Magnetic Pickup (I1 to I4 only) | 400 mV |
| Encoder Power | 5 VDC, 500 mA @40°C (104°F), 300 mA @60°C (140°F) |
| Input Impedance | 6000 ohms |
| Input Hysteresis | 250 mV typical |
| Maximum Supply Voltage | Maximum Supply Voltage |
| Maximum Output Current at 60°C (140°F) | 1.0 A for each output using 10 to 30 VDC supply |
| Output Current using 5 VDC supply | 20 mA typical |
| Inductive Load Clamp Voltage | ±8.0 V typical |
| OFF State Leakage Current | 10 µA for each output |
| Module Current Drain | 24V DC |
| Module Operating Voltage | 5 VDC (from backplane) |
