PRODUCT OVERVIEW
Technical Specifications
|
| Product family | Series 90-30 specialty I/O |
| Module function | High-speed counter processing |
| Counter resources | Four counter channels |
| Maximum count rate | Up to 80 kHz, application dependent |
| Input structure | 12 positive-logic inputs |
| Output structure | 4 positive-logic outputs |
| Counter modes | Configurable Type A, B and C operation |
| Installation | Single Series 90-30 / compatible RX3i slot |
|
02
|
FUNCTIONAL ROLE
Signal Path & System Integration
|
|
01
Field encoder or pulse source |
02
IC693APU300 local count engine |
03
Controller logic and machine sequence |
| Experienced coordination for exact-code requirements and international delivery. | Careful inspection before dispatch |
| Responsive options for urgent requirements |
|
04
|
APPLICATION CHECKPOINTS
Frequently Asked Questions
|
| Q1 |
Why use a counter module instead of ordinary discrete inputs?
It processes fast pulse events locally and exchanges resulting values with the controller.
|
| Q2 |
Can every input be wired the same way?
No. Counter mode, signal level and field wiring must match the selected configuration.
|
| Q3 |
Is IC694APU300 an automatic replacement?
No. Confirm rack support, project configuration and the complete installed catalog code.
|
| Q4 |
What should be checked before start-up?
Verify wiring polarity, input level, counter mode, presets, output loads and controller configuration.
|
|
05
|
AVAILABLE AUTOMATION PARTS
Recommended Models
|
|
06
|
PURCHASING DETAILS
Ordering Information
|
| Exact code Confirm IC693APU300, installed revision and quantity. |
Delivery planning Share destination and required date for dispatch coordination. |
Returns and replacement Contact us within seven days of receipt. Returned items must remain in original condition with a clear reason. Return shipping is handled by the buyer. |
