EMERSON DELTAV　/　INPUT ASSEMBLY
KJ3224X1-BA2
Thermocouple / mV Input Assembly
SIGNAL PATH
⌁ ━ ◇ ━ ⌁
TEMPERATURE · MILLIVOLT
INPUT TYPE
TC / mV
CHANNEL COUNT
8 channels*
BUS POWER*
12 VDC
AMBIENT RANGE*
−40 to +70°C
*Confirm exact ratings and assembly compatibility against the applicable Emerson product specification.
✦ International Delivery on the Day
✦ Quick Response Support　 ·　
✦ Intercontinental Cooperation Network
Miya Zheng · Sales Manager
✉ EMAIL SALES ☎ WHATSAPP AMIKON contact QR code



EMERSON / INDUSTRIAL AUTOMATION OverviewSpecificationsIntegrationRelated ModelsFAQ
EMERSON / LOW-LEVEL TEMPERATURE INPUT

KJ3224X1-BA2

DeltaV Series 2 Thermocouple / mV Input Module
An eight-channel DeltaV M-series Series 2 input module for thermocouple and low-level millivolt signals.
REQUEST PRICE & LEAD TIME

EXACT-CODE CHECKPOINT
Match function, power, carrier and terminal arrangement.

Sales manager: Miya zheng   |   sales@amikon.cn   |   WhatsApp 86-18020776792
02 / TECHNICAL SPECIFICATIONS

Configuration Data

Manufacturer Emerson
Model KJ3224X1-BA2
Assembly number 13P0137X022
Platform DeltaV M-series, Series 2 I/O
Input type Thermocouple and millivolt
Channels 8
Input span -100 to +100 mV
LocalBus power 12 VDC, 210 mA
Terminal key position C1
Ambient range -40 to +70 °C
03 / FUNCTIONAL ROLE & SYSTEM INTEGRATION

Installed Signal Path

This component operates as one controlled stage in the installed system. Correct service depends on the exact electrical role, physical interface, wiring arrangement and controller configuration.
