Power Consumption 3.6W typical, 4.2W maximum Operating Temperature -40°C to +70°C Isolation Voltage 1500Vrms (port-to-system) MTBF 350,000 hours @ 40°C Dimensions 128mm x 22mm x 120mm (HxWxD)
Transmission Rate 10 - 100 Mbit/s Ethernet Interfaces 1 Supply Voltage 15 V DC (from backplane) Power Consumption 3.3 W Dimensions (L×W×H) 129 × 35 × 142 mm
Main Module Operating Temp -30°C to +65°C (-22°F to +150°F) Main Module Storage Temp -40°C to +85°C (-40°F to +185°F) I/O Module Operating Temp 0°C to +65°C (+32°F to +150°F) I/O Module Storage Temp -40°C to +85°C (-40°F to +185°F) Humidity 95% non-condensing
Product ID PCD237A101 Weight 0.4 kg Dimensions (D x H x W) 250 x 30 x 110 mm Compatibility Compatible with ABB PLC systems Input/Output Channels Up to 16 channels
Part Number 1756-EN2TR UPC 612598547739 Weight 1.00 lbs (0.45 kg) Module Type Ethernet Communication Module Backplane Current (5V) 1 amp Ethernet-IP Communication Rate 10/100 Mbps Backplane Current (24V) 3 milliamps
