DS822.OD110 Engineering Profile
|
||||||||||||||||||||||||||
|
|
|
||||||||||||||||||||||||
|
03 / MEASUREMENT SYSTEM
How DS822.OD110 Fits the Chain
The driver is not a stand-alone displacement probe. It forms the electronic driver stage of the ds822 Ex system and is paired with the corresponding ds822 displacement sensor and system cabling.
SIGNAL PATH
Displacement Sensor → Connection Cable → DS822.OD110 → Monitoring Electronics
|
|
|
04 / SERIES RELATIONSHIP
ds82x Family Positioning
The principal distinction within the family is the measurement range and hazardous-area configuration.
|
|||
|
ds821
Standard version
For standard industrial environments.
|
ds822
Ex version
Designed for hazardous-area applications with applicable Ex approvals.
|
2 mm
Measurement range
Blue identification for the 2 mm measuring range.
|
OD110
Driver configuration
Driver designation used with the 5 m / 10 m system configuration.
|
|
05 / PROCUREMENT SUPPORT
Need DS822.OD110?
Send the exact part number, required quantity, destination and required date for a focused quotation.
|
|
|
06 / BUYER QUESTIONS
DS822.OD110 FAQ
|
|
|
Can DS822.OD110 be used with both 5 m and 10 m ds822 systems?
Yes. The od110 driver configuration is specified for nominal 5 m and 10 m system lengths. The driver concept allows the system length to be accommodated without requiring a different driver for those two lengths.
|
What should buyers match with DS822.OD110 when replacing a driver?
The replacement should be matched to the ds822 Ex system configuration, including the 2 mm measurement range and the applicable nominal system length. The associated sensor and connection cable should be checked as a complete measurement chain.
|
|
Why does DS822.OD110 matter when monitoring shaft displacement?
The driver provides the oscillator and demodulator functions required to turn the non-contact eddy-current measurement into a proportional voltage signal for downstream monitoring equipment.
|
Does DS822.OD110 indicate the hazardous-area version of the system?
The DS822 family is the Ex version of the ds82x displacement system. Applicable approvals and installation requirements depend on the complete ds822 configuration and the intended hazardous area.
|
|
What is the practical advantage of the DS822.OD110 driver arrangement for maintenance?
The ds82x architecture uses a compact driver and self-latching push-pull connections, supporting straightforward installation and helping reduce the number of different driver variants needed for 5 m and 10 m system configurations.
|
|
|
