A 3300 NSv proximity probe configured for M10X1 mounting, armored construction and a 7.0 m total length, designed for compact machinery-monitoring installations where conventional probe systems face space or target-size limitations.
The 3300 XL NSv system is intended for machinery where installation geometry is restrictive or the measurement target is relatively small. Its design supports radial vibration, radial position, axial position, tachometer/zero-speed and Keyphasor measurements on appropriate fluid-film bearing machines.
The NSv design is particularly suited to machinery where conventional proximity systems cannot be comfortably installed because of counterbore, side-view or rear-view restrictions.
Applicable to centrifugal air compressors, refrigeration compressors and process gas compressors.
Supports radial vibration and radial position measurements.
Suitable for axial or thrust-position monitoring on appropriate machine targets.
Can be applied for tachometer, zero-speed and Keyphasor phase-reference measurements.
Typical replacement demand can arise when an installed NSv probe, cable connection or associated measurement channel no longer provides the expected machine-monitoring signal.
Loss of a vibration, position, speed or phase-reference measurement can reduce the availability of a machine's monitoring channel and complicate condition-based operating decisions.
Thread, case length, total cable length, connector/cable configuration and approval option are encoded in the complete part number.
330910-00-06-70-02-05
The 3300 XL NSv system was designed for applications where counterbore, side-view or rear-view restrictions limit the use of standard 5 mm and 8 mm systems.
In the metric ordering structure, “70” specifies a total probe length of 7.0 meters.
Option 02 specifies a miniature coaxial ClickLoc connector with standard cable.
The specified linear range is 1.5 mm, extending approximately from 0.25 mm to 1.75 mm from the target.
The recommended gap setting is 1.0 mm, or approximately 40 mils, under the stated system conditions.
Depending on the installation, it supports radial vibration, radial position, axial position, tachometer/zero-speed and Keyphasor phase-reference measurements.
When an exact automation part is needed, clear part identification and fast communication help reduce unnecessary delays.
Our multilingual support team and customized order-tracking process are designed to make industrial automation sourcing more straightforward, especially when an exact part number is critical.
Send the part details once. Our sales team can check the requested configuration and arrange the next step.
The 3500/22M 138607-01 Transient Data Interface (TDI) is the interface between the 3500 monitoring system and compatible software (System 1 Condition Monitoring and Diagnostic software and 3500 System Configuration software). The TDI combines the function of a 3500/20 Rack Interface Module (RIM) with the data collection capability of a communication processor such as TDXnet.
3500/22M is a Transient Data Interface Module manufactured and designed by Bently Nevada as part of the 3500 Series used for monitoring seismic activity. The 3500/22M Transient Data Interface (TDI) is the interface between the 3500 monitoring system and compatible software (System 1 Condition Monitoring and Diagnostic software and 3500 System Configuration software). The TDI combines the function of a 3500/20 Rack Interface Module (RIM) with the data collection capability of a communication processor such as TDXnet.
The 3500/33 16-Channel Relay Module is a full-height module that provides 16 relay outputs. You can place any number of 16-channel relay modules in any of the slots to the right of the Transient Data Interface (TDI) Module. Each output of the 3500/33 16-Channel Relay Module can be independently programmed to perform voting logic.
The 3500/60 & 61 modules provide six channels of temperature monitoring and accept both Resistance Temperature Detector (RTD) and Thermocouple (TC) temperature inputs. The modules condition these inputs and compare them against user-programmable alarm setpoints. The 3500/60 and 3500/61 provide identical functionality except that the 3500/61 provides recorder outputs for each of its six channels while the 3500/60 does not.
The 3500/60 & 61 modules provide six channels of temperature monitoring and accept both Resistance Temperature Detector (RTD) and Thermocouple (TC) temperature inputs. The 3500/60 133811-01 modules condition these inputs and compare them against user-programmable alarm setpoints. The 3500/60 and 3500/61 provide identical functionality except that the 3500/61 provides recorder outputs for each of its six channels while the 3500/60 does not.
The 3500/72M Recip Rod Position Monitor meets API 618 requirements for reciprocating compressors. It measures: l Rod position l Rod drop l Hyper-compressor The four-channel 3500/72M Recip Rod Position Monitor accepts input from proximity transducers, conditions the signal to provide dynamic and static position measurements, and compares the conditioned signals with userprogrammable alarms. Each channel, depending on how you configure it, typically conditions its input signal to generate various parameters called measured values.
The 3500/62 Process Variable Monitor is a 6-channel monitor for processing machine critical parameters that merit continuous monitoring, such as pressures, flows, temperatures, and levels. The monitor accepts +4 to +20 mA current inputs or any proportional voltage inputs between -10 Vdc and +10 Vdc. It conditions these signals and compares the conditioned signals to user-programmable alarm setpoints.
The 3500/62 Process Variable Monitor is a 6-channel monitor for processing machine critical parameters that merit continuous monitoring, such as pressures, flows, temperatures, and levels. The monitor accepts +4 to +20 mA current inputs or any proportional voltage inputs between -10 Vdc and +10 Vdc. It conditions these signals and compares the conditioned signals to user-programmable alarm setpoints.
