Metric 3300 NSv Proximity Probe with M8X1 thread, armored construction and a 5-meter cable configuration, designed for compact machinery monitoring installations.
The 3300 XL NSv system is intended for machinery where installation space is restricted, including centrifugal air compressors, refrigeration compressors, process gas compressors and other fluid-film-bearing machines with small shafts or limited side-view access.
This type of probe is commonly considered when a machinery monitoring channel needs replacement because of probe or cable damage, unstable proximity signals, installation constraints, or a need to restore an existing NSv measurement point. For critical rotating equipment, loss of a reliable vibration or position measurement can reduce monitoring visibility and may contribute to an increased risk of unplanned downtime if the affected channel is part of the machine protection strategy.
Our service is built around speed, clear communication and practical support for industrial automation requirements. Whether a replacement is needed for an active machine or a spare is being prepared for maintenance, our team focuses on identifying the correct part configuration and responding efficiently.
It is a 3300 NSv proximity probe with an M8X1 threaded, armored configuration.
The ordering configuration specifies a 5.0-meter probe cable with a miniature coaxial ClickLoc connector and standard cable.
It is intended for centrifugal air compressors, refrigeration compressors, process gas compressors and other machines where installation space is restricted.
The system supports radial vibration and radial position, axial position, tachometer/zero-speed and phase-reference applications.
The probe operating temperature range is −52°C to +177°C.
The recommended gap setting is 1.0 mm (40 mils), within the specified linear measurement range.
To identify the correct configuration and respond efficiently, please include the following information in your inquiry:
The 3500/22M 138607-01 Transient Data Interface (TDI) is the interface between the 3500 monitoring system and compatible software (System 1 Condition Monitoring and Diagnostic software and 3500 System Configuration software). The TDI combines the function of a 3500/20 Rack Interface Module (RIM) with the data collection capability of a communication processor such as TDXnet.
3500/22M is a Transient Data Interface Module manufactured and designed by Bently Nevada as part of the 3500 Series used for monitoring seismic activity. The 3500/22M Transient Data Interface (TDI) is the interface between the 3500 monitoring system and compatible software (System 1 Condition Monitoring and Diagnostic software and 3500 System Configuration software). The TDI combines the function of a 3500/20 Rack Interface Module (RIM) with the data collection capability of a communication processor such as TDXnet.
The 3500/33 16-Channel Relay Module is a full-height module that provides 16 relay outputs. You can place any number of 16-channel relay modules in any of the slots to the right of the Transient Data Interface (TDI) Module. Each output of the 3500/33 16-Channel Relay Module can be independently programmed to perform voting logic.
The 3500/60 & 61 modules provide six channels of temperature monitoring and accept both Resistance Temperature Detector (RTD) and Thermocouple (TC) temperature inputs. The modules condition these inputs and compare them against user-programmable alarm setpoints. The 3500/60 and 3500/61 provide identical functionality except that the 3500/61 provides recorder outputs for each of its six channels while the 3500/60 does not.
The 3500/60 & 61 modules provide six channels of temperature monitoring and accept both Resistance Temperature Detector (RTD) and Thermocouple (TC) temperature inputs. The 3500/60 133811-01 modules condition these inputs and compare them against user-programmable alarm setpoints. The 3500/60 and 3500/61 provide identical functionality except that the 3500/61 provides recorder outputs for each of its six channels while the 3500/60 does not.
The 3500/72M Recip Rod Position Monitor meets API 618 requirements for reciprocating compressors. It measures: l Rod position l Rod drop l Hyper-compressor The four-channel 3500/72M Recip Rod Position Monitor accepts input from proximity transducers, conditions the signal to provide dynamic and static position measurements, and compares the conditioned signals with userprogrammable alarms. Each channel, depending on how you configure it, typically conditions its input signal to generate various parameters called measured values.
The 3500/62 Process Variable Monitor is a 6-channel monitor for processing machine critical parameters that merit continuous monitoring, such as pressures, flows, temperatures, and levels. The monitor accepts +4 to +20 mA current inputs or any proportional voltage inputs between -10 Vdc and +10 Vdc. It conditions these signals and compares the conditioned signals to user-programmable alarm setpoints.
The 3500/62 Process Variable Monitor is a 6-channel monitor for processing machine critical parameters that merit continuous monitoring, such as pressures, flows, temperatures, and levels. The monitor accepts +4 to +20 mA current inputs or any proportional voltage inputs between -10 Vdc and +10 Vdc. It conditions these signals and compares the conditioned signals to user-programmable alarm setpoints.
