The sensor supplies power to the matched probe, conditions the eddy-current signal and provides an output proportional to probe-to-target gap. This supports both static position and dynamic vibration measurement.
Radial vibration and shaft position.
Keyphasor and speed-related signals.
Machinery protection system input.
Exact X1 / MOD calibration.
Technical basis: Baker Hughes official 3300 XL 8 mm Proximity Transducer System datasheet ↗
It powers the probe and converts the eddy-current response into a usable voltage signal.
No. It identifies a special configuration that must match the installed system.
It denotes the multiple-approval option in the standard 3300 XL ordering structure.
On turbines, compressors, pumps, motors and other fluid-film-bearing machinery.
Send the full part number, MOD number, nameplate photo, quantity and destination.
AMIKON supplies industrial automation and machinery-monitoring parts to system integrators, OEM and MRO teams. Our stock and logistics network supports scheduled maintenance, modernization and urgent replacement projects worldwide.
Miya Zheng can assist with stock, pricing and delivery.
