BENTLY NEVADA 330180-X1-05 MOD: 145004-75 3300 XL 8 mm Proximitor Sensor

BENTLY NEVADA 330180-X1-05 MOD: 145004-75
BENTLY NEVADA 330180-X1-05 MOD: 145004-75
BENTLY NEVADA 330180-X1-05 MOD: 145004-75

BENTLY NEVADA 330180-X1-05 MOD: 145004-75 3300 XL 8 mm Proximitor Sensor

Calculate shipping
Quotation Request
BENTLY NEVADA / 3300 XL
330180-X1-05
MOD: 145004-75
PRODUCT FAMILY
Proximitor Sensor
Proximity signal conditioning
For compatible eddy-current proximity transducer systems.
SENSOR FEATURES
01 / SIGNAL
Probe signal conditioning
Converts probe response into a conditioned voltage output.
02 / CONNECTION
SpringLoc terminals
Tool-free terminal wiring on the 3300 XL sensor family.
03 / MOUNTING
DIN rail or panel
Select the installed mounting arrangement when replacing.
ASK FOR AVAILABILITY
AMIKON LIMITED
Sales manager: Miya zheng
✉ EMAIL AMIKON ☏ 86-18020776792
  AMIKON contact QR





MACHINERY MEASUREMENT PATH / 330180
330180-X1-05 MOD: 145004-75

3300 XL 8 mm Proximitor Sensor
A 3300 XL 8 mm Proximitor Sensor carrying multiple agency approvals and modification identifier 145004-75. The X1 position represents the ordered total-length and mounting execution and must be resolved from the unit label or purchase record before replacement. The MOD identifier is part of the exact configuration and must be retained.
SIGNAL CONDITIONING / MODIFIED CALIBRATION EXECUTION
◇ Sales manager: Miya zheng REQUEST QUOTE / EMAIL WHATSAPP 86-18020776792
01
TECHNICAL SPECIFICATIONS
Ordered Configuration and Performance Context

Product family 3300 XL 8 mm Proximity Transducer System
Base catalog pattern 330180-X1-05
Modification identifier 145004-75
Approval option 05 - multiple approvals
X1 field Total system length and mounting option; exact value required
Sensor role Probe-signal conditioning and monitor output
Compatible probe family 3300 XL 8 mm
Nominal system scale factor 7.87 V/mm (200 mV/mil)
Nominal linear range 2 mm (80 mil)
Typical supply -24 Vdc nominal
02
FUNCTIONAL ROLE & SYSTEM INTEGRATION
Where This Component Sits in the Measurement Chain

TARGET → SENSOR → MONITOR The Proximitor Sensor excites the eddy-current probe and conditions the returned signal into a voltage proportional to probe-to-target distance. It is the electronic interface between the 8 mm probe/cable assembly and a vibration, position or Keyphasor measurement input. Modification 145004-75 and the resolved X1 mounting/system-length option must remain attached to procurement and calibration decisions.
20 YEARS / INDUSTRIAL AUTOMATION SUPPLY
Keep Critical Machinery Moving
AMIKON supports urgent and planned automation requirements with responsive quotations, careful part matching and international delivery coordination.



◇ Sales manager: Miya zheng CHECK AVAILABILITY / EMAIL WHATSAPP 86-18020776792
04
FREQUENTLY ASKED QUESTIONS
Five Procurement and Engineering Checks

01
330180-X1-05 MOD: 145004-75 - Why is X1 not enough for ordering?
X1 contains a variable length/mounting selection. The actual digits must be confirmed from the installed label before a direct replacement is chosen.
02
330180-X1-05 MOD: 145004-75 - Can a standard 330180 replace MOD 145004-75?
Not automatically. The modification may affect calibration or application execution, so the exact MOD identity and target/application requirements must be confirmed.
03
330180-X1-05 MOD: 145004-75 - Can this sensor be paired with a 25 mm probe?
No. It belongs to the 3300 XL 8 mm system and is not the signal conditioner for the 25 mm family.
04
330180-X1-05 MOD: 145004-75 - What should be recorded before removal?
Record the full catalog number, MOD number, mounting arrangement, probe and extension-cable numbers, target material and monitor-channel configuration.
05
330180-X1-05 MOD: 145004-75 - What is required after replacement?
Confirm power, gap voltage, scale factor, alarm/channel configuration and the response of the complete probe–cable–Proximitor chain.
05
FINAL INQUIRY CTA
Confirm the Complete Installed Execution

Send the complete catalog code, MOD identifier, quantity, destination and clear label photographs. For replacement work, include the connected probe, cable, Proximitor Sensor or housing details as applicable.
◇ Sales manager: Miya zheng SEND INQUIRY / EMAIL WHATSAPP 86-18020776792
06
RECOMMENDED MODELS
Industrial Automation Parts

3HAC17396-1 ATG-50140 3HAC046277-001 416NHM30030A IC694ALG442-ED
80PS080X3.10-01 HE693RTD600R PR6423/003-110 AJ65BTB2-16D 24701-28-05-00-070-04-02
IC200ALG431 3500/92-04-01-01 6ES7341-1AH02-0AE0 3-LDSM 6ES7193-6PA00-0AA0
3500/33-SIL2-03-01 6ES7214-1BG31-0XB0 3500/22M-01-01-01 F8628X PR9268/617-100-CNS
140ACI03000C PR9268/207-100 VS7-6-FG-D-3N 6ES7214-2BD23-0XB8 5X00119G01
PR9268/601-000 X20BT9100 330106-05-30-10-02-00 KSP600-3X20 SNB10D-425-CU2N
PR9268/200-000 6ES7534-7QE00-0AB0 AAI841-H50 S2SC70D-SA11010 MVS0390X08S060
F8641 7402-040-01 2711-K5A16L1 F8627X IC695HSC304
S2SC70D-SA12010 8V1016.00-2 IC694PWR330A PR9268/203-100 330106-05-30-05-02-05
PR6423/011-040 IC695ETM001-LBAA C5-570-32-RF CXS-A1000-10 PR6424/011-110
2711P-B6M20D 6ES7416-2XN05-0AB0 SDV541-S63/PRP F8640 IC200CHS022
3RH1921-1FA40 AAI135-S50/K4A00 PR6424/000-031 82A-0A-BRA P-HC-BRC-41000000
Return and Replacement Coordination
Contact us within seven days if a concern appears after delivery. Items should remain in their original condition with the return reason provided. Return or replacement is arranged after receipt and inspection. Return-related shipping costs are arranged by the buyer.
07
ORDERING INFORMATION
Price, Availability and Delivery

For an exact-match quotation, provide the full catalog code, MOD number where applicable, requested quantity, condition and delivery destination. Compatibility approval should be based on the complete installed measurement chain rather than the family prefix alone.
