LEGACY / ASSOCIATED
24710-080-01
The requested Bently Nevada designation is cross-associated with 7402-080-01 and MX2031-080-01-00 in vibration-monitoring cross-reference data. |
CABLE FAMILY RELATION
Length / armor / system matching
|
CURRENT CROSS-REFERENCE
MX2031-080-01-00
The MX2031 designation represents the corresponding Metrix extension-cable family entry associated with the 080 / 01 configuration. |
|
24710 Series
Legacy Bently Nevada cable designations including length and configuration variations.
|
7402 Series
The 24710-080-01 cross-reference is associated with Metrix 7402-080-01.
|
MX2031 Family
Extension-cable family with multiple cable-length and configuration combinations.
|
| 24710-080-01 | 8.0 m class / armored configuration |
| 7402-080-01 | Cross-associated Metrix designation |
| MX2031-080-01-00 | Corresponding MX2031 configuration |
|
Inquiry Details
For faster quotation, please include the required quantity, destination and required delivery date. EMAIL SALES WHATSAPP |
|
DELIVERY
3–5 Days
|
WARRANTY
12 Months
|
PACKAGING
Brand New
|
PAYMENT
T/T
|
Please contact us within 7 days if you have any question after you receiving the items.
The returned items has to be in its original condition, with a specific reason for the return. We will issue a return or replacement for your order after we received the returns.
The buyer is responsible for all the shipping cost incurred.
|
Q1. How should 24710-080-01 be checked when replacing an installed cable?
The complete designation should be matched, especially the 080 length configuration and 01 armored configuration. Matching only the base 24710 family is not sufficient when the installed system depends on a specific cable length and mechanical construction.
|
|
Q2. Can 24710-080-01 be treated as interchangeable with every 24710 cable?
No. The 24710 family includes different cable-length and configuration variants. The 080 / 01 combination represents a particular configuration, so the installed arrangement should be matched by the complete part number rather than by the series name alone.
|
|
Q3. What should be checked if a buyer wants to replace 24710-080-01 with a newer designation?
The receiving system should be checked against the complete sensing chain. The 24710-080-01 designation is cross-associated with Metrix 7402-080-01 and MX2031-080-01-00, but a cross-reference should not be treated as a substitute for confirming the actual installed probe, cable arrangement and monitoring electronics.
|
|
Q4. Does the 080 designation of 24710-080-01 matter for maintenance planning?
Yes. The 080 configuration is associated with an 8.0 m cable-length class. Cable length affects routing between the sensing location and monitoring electronics, so the replacement should maintain the required installed cable run rather than being selected only by physical appearance.
|
|
Q5. When requesting 24710-080-01, what should be included in the quotation inquiry?
Provide the exact part number 24710-080-01, required quantity, destination, required date and the machine or monitoring system in which the cable is installed. If replacing an existing cable, including the connected probe and receiving electronics helps reduce configuration uncertainty.
|
