Allen Bradley 80190-320-03-R Customer Interface Board

descriptions

Function: Customer Interface Board (CIB) for PowerFlex 7000 MV drives

Supply voltage: 24 V DC ±10 %

Operating temp: -20 °C … +70 °C ambient

Storage temp: -40 °C … +85 °C

Dimensions: 150 mm × 100 mm × 25 mm

Weight: ≈ 0.5 kg

Isolation: 3 kV AC (1 min) power-to-logic

Interfaces: RS-485 + EtherNet/IP on-board

Mounting: Plug-in to drive back-plane, captive screws

Summary

The Allen-Bradley 80190-320-03-R is the Customer Interface Board that links the PowerFlex 7000 medium-voltage drive to the outside world. Running on 24 V DC and -20 °C … +70 °C, it gives you both RS-485 and EtherNet/IP in one slot, so you can start, stop, trim speed or read power without extra gateways. Its 3 kV isolated front-end keeps plant PLCs safe from the 4 kV DC bus, and the 0.5 kg plug-in design lets you swap it in minutes—no re-cabling, no laptop re-flash.

Q&A

1.How fast can Amikon really ship hard-to-find parts?

Amikon commits to 24-hour dispatch on all in-stock items; spot inventory ships the same day via UPS, DHL, FEDEX or TNT to any of 167 countries.

2. What if the part I need is discontinued or rare?

Amikon carries over 1 million new and obsolete industrial parts in a 63,000 sq ft warehouse—if it exists, Amikon will source it and deliver it.

3: How does Amikon protect my purchase?

Every part is shipped in original or certified international packaging and is covered by a 12 months comprehensive warranty.
