ALLEN-BRADLEY / FLEX I/O
1794-PS1
FLEX I/O Power Supply Module
The Allen-Bradley 1794-PS1 is an AC-input power supply module for the FLEX I/O platform. It converts an AC supply into 24V DC power for FLEX I/O adapters and associated I/O architecture, providing a compact power source for distributed automation installations.
FLEX I/O AC INPUT 24V DC OUTPUT
|
BULLETIN 1794
1794-PS1
FLEX I/O POWER SUPPLY
120 / 230 VAC → 24 VDC
|
|
|
||||||||||||||||||||||||||||
|
POWER BUDGET
The 37W real-input value is useful when evaluating enclosure heat dissipation.
|
TRANSFORMER SIZING
The 93VA transformer-load value should be considered together with other transformer loads.
|
SYSTEM MARGIN
The 1.0A 24V DC user output rating provides the basis for evaluating the connected FLEX I/O load.
|
|
APPLICATION VIEW
Designed Around FLEX I/O Power Distribution
1794-PS1 is intended for installations where the FLEX I/O architecture requires an AC-input power source capable of providing 24V DC to the distributed I/O power path.
Its compact form factor allows the power supply to sit within the same distributed automation environment as the FLEX I/O adapter and I/O modules.
Design Focus
Match the supply capacity to the actual system load and consider the power requirements of the complete FLEX I/O installation.
|
|
||||||
|
1794-PS1
AC-input FLEX I/O power supply with 24V DC user output up to 1.0A.
|
1794-PS13
FLEX I/O AC power supply option with a higher 24V DC user-output capacity than 1794-PS1.
|
1794-PS3
Another FLEX I/O power-supply option intended for installations with different distributed-power requirements.
|
|
PROJECT / REPLACEMENT SUPPORT
Need 1794-PS1?
Contact our sales team for availability, replacement requirements, quantity planning and delivery coordination.
|
✉ EMAIL · sales@amikon.cn ◉ WHATSAPP · 86-18020776792
Sales Manager: Miya Zheng
|
|
Can 1794-PS1 be used when the FLEX I/O system requires a 24V DC power source?
Yes. 1794-PS1 provides a 24V DC user output rated up to 1.0A. The actual system load should be checked before selecting the supply.
|
Is 1794-PS1 suitable for both 120V AC and 230V AC installations?
Its nominal input is specified as 120/230V AC, with an operating input range of 85–264V AC and an input frequency range of 47–63 Hz.
|
|
How should 1794-PS1 be evaluated when calculating cabinet power requirements?
Use the 37W real-input value when considering enclosure heat dissipation, the 71VA apparent-power value for electrical loading, and the 93VA transformer-load value for transformer sizing.
|
What should be checked before replacing an existing 1794-PS1?
Verify the FLEX I/O architecture, AC input requirements, required 24V DC load, environmental conditions and the complete connected power demand before replacement.
|
|
Why might 1794-PS1 be considered when maintaining an existing FLEX I/O installation?
Its role is specifically aligned with the FLEX I/O distributed power architecture, while its compact dimensions and defined 24V DC output capacity make electrical and mechanical compatibility important parts of the replacement decision.
|
|
|
SERVICE POLICY
Return / Replacement
|
Please contact us within 7 days if you have any question after you receiving the items.
The returned items has to be in its original condition, specific reason for the return, we will issue a return or replacement for your order after we received the returns.
The buyer is responsible for all the shipping cost incurred.
|
|
