Allen Bradley 150-F135NBDB State Controller

Allen Bradley 150-F135NBDB State Controller



⚡ SMC-FLEX MOTOR CONTROL
150-F135NBDB
Allen-Bradley Soft Starter
Pump-control configuration with internal run bypass for controlled three-phase motor starting and stopping.
◆ OPEN CONTROLLER   ◆ PUMP DUTY

THREE ENGINEERING CHECKPOINTS
A 135 A
Controller current rating
V 200-480 VAC
Three-phase line supply
C 100-240 VAC
Control power range

DIRECT CONTACT
Contact QR code ✉ sales@amikon.cn ☎ 86-18020776792
Sales manager
Miya zheng
ALLEN-BRADLEY / MOTOR CONTROL OVERVIEWRATINGSCONTROLSELECTIONFAQ
⚡ SMC-FLEX / OPEN SMART MOTOR CONTROLLER
150-F135NBDB
135 A Soft Starter with Pump Control

Designed for controlled starting and stopping of three-phase motors, combining solid-state switching, an internal run bypass, electronic overload protection and a pump-focused control profile in one open controller.
135 A
CONTROLLER RATING
200-480 V
THREE-PHASE LINE
100-240 V
CONTROL POWER
25-100 hp
AT 460 V
◉ Sales manager: Miya zheng ✉ sales@amikon.cn ☎ 86-18020776792
◆ ELECTRICAL & MECHANICAL MATCH
Values That Determine the Correct Fit
POWER CIRCUIT
200-480 VAC
3-phase, 50/60 Hz
135 A controller rating
CONTROL CIRCUIT
100-240 VAC
electromagnetic auxiliary relay
programmable NO/NC contact
MECHANICAL
Open construction
443.7 × 196.4 × 212.2 mm
15 kg
Auxiliary contact duty 3 A at 120 VAC; 1.5 A at 240 VAC Internal bypass Included for reduced run-state heat
⇄ CONTROL BEHAVIOR
What the Pump-Control Configuration Adds
↗
CONTROLLED START
Reduces abrupt motor acceleration and mechanical stress compared with across-the-line starting.
∼
PUMP CONTROL
The NBDB option is selected for pump applications where torque transitions and hydraulic behavior require attention.
■
RUN BYPASS
The internal bypass carries the motor current after acceleration, reducing steady-state semiconductor heat.
OVERLOAD CLASSES
Selectable trip classes 10, 15, 20 and 30 support different motor acceleration and thermal profiles.
PTC MONITORING
The controller supports a PTC sensor chain; the permitted sensor count and resistance limits must match the motor installation.
STATUS VISIBILITY
Operating states include stopped, starting, stopping, at speed, alarm and fault indications.
⚙ APPLICATION ENGINEERING
Checks Before the Starter Enters Service
MOTOR MATCH Use motor nameplate current, starting torque, acceleration time and duty cycle- not horsepower alone.
ENCLOSURE Provide a suitable enclosure, clearances, ventilation and ambient-temperature margin for the open controller.
PROTECTION Coordinate branch protection, short-circuit rating, isolation and grounding with the available fault current.
PUMP SYSTEM Confirm valve position, check-valve response, static head and required pressure transition during starting and stopping.
⇆ ORDER-CODE DECISION
Do Not Treat Similar SMC-Flex Codes as Equal
150-F135NBDB 150-F135NBD HIGHER / LOWER CURRENT FRAME
135 A frame with 100-240 VAC control power and Pump Control.

Choose when: the installed application explicitly requires the NBDB pump configuration.
Same 135 A base family without the final Pump Control suffix.

Choose when: the existing motor process does not require the NBDB option and the full code matches.
Current-frame changes affect power hardware, dimensions, protection and thermal design.

Choose only after: motor current and enclosure design are recalculated.

◉ AMIKON PARTS TEAM
WHY CHOOSE AMIKON?
Support for urgent, rare and discontinued automation parts.
✓ Legacy-system continuity -extend useful equipment life without unnecessary platform replacement.
→ Responsive coordination -urgent requirements receive prompt order and delivery attention.
◆ Practical order checks -exact model, condition and supplied scope are aligned before shipment.
12-month warranty. Raise concerns within seven days of receipt. Returned goods must remain in original condition with the reason stated. Return freight is arranged by the buyer.
◉ Sales manager: Miya zheng ✉ sales@amikon.cn ☎ 86-18020776792
▣ PROCUREMENT FAQ
Five Decisions Before Ordering 150-F135NBDB
01 Can 150-F135NBDB be installed without a panel enclosure? No. Its open construction requires a suitable enclosure with correct clearances, ventilation and protection.
02 Is 150-F135NBDB selected only by motor horsepower? No. Motor full-load current, starting torque, acceleration time, duty cycle and ambient conditions govern selection.
03 What does the final B mean in 150-F135NBDB? It denotes the Pump Control option; a different suffix may change application behavior.
04 Does 150-F135NBDB require an external run bypass contactor? The controller includes an internal bypass. Verify the installed isolation and circuit architecture before changing hardware.
05 What should be supplied with a 150-F135NBDB inquiry? Provide motor nameplate current, line and control voltage, pump duty, existing full code, enclosure conditions and destination.
