Part Number |
1336-QOUT-SP13A |
|
Weight |
1.88 lbs (0.85 kg) |
|
Power Rating at 230 VAC |
50 HP |
|
Power Rating at 460 VAC |
100 HP |
|
Frame Type |
D Frame |
|
Manufacturer |
Allen Bradley |
OUR TEAM
l Same-day dispatch on 1000s of parts
l Our company under the Ministry of market sales, technical Works, after-sales service, integrated management of the Department.
We can help your business well with thoughful
l Sales department 24/7 hours service. Deal your request for any PLC DCS products promptly, patiently and professionally.
l Engineering department Ensure that there are no quality problems in the products.All products will be examed before shipment.
l Financial department Check payment and refund in time.
l Warehouse department Careful checking the goods listing and careful packing, shipping goods in time.
l After-sales service department Full-time after-sales service team, under the sales department, the user can put the timely response to service requests.
⇒Sales manager: Miya zheng Email: sales@amikon.cn WhatsApp: 86-18020776792
Descripution
Allen Bradley's 1336-QOUT-SP13A is classified as an output transistor module, specifically designed to work within the 1336 Transistor Assembly framework. This module can handle 50 horsepower at 230 volts AC and up to 100 horsepower at 460 volts AC. It utilizes a D frame design, facilitating the integration of up to three units per drive, thus optimizing space and performance.
Operating at temperatures reaching up to 40°C, the module is suitable for a wide range of environments. It also has an impressive altitude capability, rated for use at up to 2000 meters above sea level. The humidity tolerance ranges from 5% to 95%, ensuring functionality in various conditions without condensation.
For storage, it can resist temperatures up to 85°C, indicating robust construction suitable for different industrial setups. An essential aspect is the motor overload capacity, rated at 115% of full load amps, which allows for some leeway during transient conditions. Internally, it features a Fuji 1MBI300JN-120 IGBT transistor, capable of withstanding high voltage levels up to 1200 V.
Technical specifications
|
Manufacturer |
Allen Bradley |
|
Product Type |
Output Transistor Module |
|
Product Line |
1336 Transistor Assembly |
|
Part Number |
1336-QOUT-SP13A |
|
Weight |
1.88 lbs (0.85 kg) |
|
Power Rating at 230 VAC |
50 HP |
|
Power Rating at 460 VAC |
100 HP |
|
Frame Type |
D Frame |
|
Units per Drive |
3 Units |
|
Operating Ambient Temperature |
Up to 40°C |
|
Altitude Rating |
2000 m |
|
Relative Humidity |
5% to 95% non-condensing |
|
Storage Temperature Range |
Up to 85°C |
|
Motor Overload Capacity |
115% of full load amps |
|
Internal Transistor Model |
Fuji 1MBI300JN-120 IGBT |
|
Voltage Withstand |
1200 V |
1336-QOUT-SP13A FAQ
|
Question: |
How does the AB 1336-QOUT-SP13A enhance the operational resilience of Allen-Bradley 1336 AC drive systems? |
|
Anwser: |
The AB 1336-QOUT-SP13A is engineered as a replacement output assembly that helps restore the original functionality of the drive, ensuring dependable signal processing and maintaining consistent motor control performance in demanding industrial environments. |
|
Question: |
Why should maintenance engineers specify the AB 1336-QOUT-SP13A when refurbishing legacy 1336 drive platforms? |
|
Anwser: |
The AB 1336-QOUT-SP13A provides a reliable spare solution for replacing deteriorated output components, reducing unexpected downtime while extending the service life of existing Allen-Bradley 1336 variable frequency drives. |
|
Question: |
Which compatibility parameters should be meticulously verified before installing the AB 1336-QOUT-SP13A? |
|
Anwser: |
Before integrating the AB 1336-QOUT-SP13A, engineers should validate the drive series, hardware revision, electrical interface, connector configuration, and installation requirements to ensure seamless system compatibility and optimal operational reliability. |
|
Question: |
What diagnostic indicators could suggest that the AB 1336-QOUT-SP13A requires replacement or inspection? |
|
Anwser: |
Symptoms such as unstable drive output, intermittent motor operation, abnormal fault conditions, or degraded control response may indicate that the AB 1336-QOUT-SP13A should be inspected or replaced as part of a comprehensive maintenance strategy. |
|
Question: |
In which industrial automation applications does the AB 1336-QOUT-SP13A provide the greatest engineering value? |
|
Anwser: |
The AB 1336-QOUT-SP13A is widely utilized in manufacturing, material handling, mining, pulp and paper, water treatment, and other industrial facilities where Allen-Bradley 1336 drives are employed to deliver reliable and continuous motor control. |
