Manufacturer |
Allen Bradley |
|
Product Type |
Main Control Board (MCB) |
|
Product Line |
1336 PLUS Drives |
|
Part Number |
1336S-MCB-SP1 |
|
Weight |
1.13 lbs (0.51 kg) |
|
UPC |
820919779510 |
|
Frame |
B-H FRAME |
|
Connector Type |
Edge and pin headers |
|
Potentiometer Input |
10 kΩ |
|
Analog Input – Voltage |
0–10 VDC |
|
Analog Input – Current |
4–20 mA |
|
Vibration Tolerance |
1 G |
|
Control Type |
Sensorless Vector |
|
Efficiency |
97.50% |
|
Input Frequency |
48-62 Hz |
|
Operating Temperature Range |
0 °C to +40 °C |
|
Storage Temperature Range |
−40 °C to +70 °C |
|
Relative Humidity |
5 % to 95 % non-condensing |
|
Altitude |
1000 m |
Description
|
The Allen Bradley model 1336S-MCB-SP1 serves as the main control board (MCB) for the 1336 PLUS Drives series. This component operates effectively within a B-H frame size. Designed for high-performance requirements, it features edge and pin headers for connectivity. |
|
This control board accepts a potentiometer input of 10 kΩ and supports analog inputs for voltage ranging from 0 to 10 VDC and current from 4 to 20 mA. Operating with a sensorless vector control type, the efficiency rating stands at an impressive 97.50%, which is vital for minimizing energy loss. |
|
The unit is designed to function with an input frequency between 48 Hz and 62 Hz. It is capable of operating in temperatures from 0 °C to +40 °C and can withstand storage conditions between −40 °C and +70 °C. Additionally, the board has a vibration tolerance of 1 G, ensuring durability in fluctuating environments. It is rated for operation at altitudes up to 1000 meters and can handle a relative humidity range of 5% to 95% without condensation. With its robust configuration, the 1336S-MCB-SP1 provides reliability and efficiency for various industrial applications. |
FQA
Q1、What is Allen Bradley 1336-MCB-SP1 74100-071-51?
The Allen Bradley 1336-MCB-SP1 74100-071-51 is a Main Control Board designed for the 1336 Plus series adjustable frequency AC drives. It is responsible for processing control signals, managing analog and digital I/O communication, and supporting drive operation in industrial automation systems. The module is commonly used in manufacturing, process control, and motor drive applications.
Q2、What are the main functions of the 1336-MCB-SP1 board?
This control board handles signal interfacing, analog input processing, relay output control, and communication between the drive and connected devices. It supports potentiometer input, 0–10VDC and 4–20mA analog inputs, pulse input functions, and multiple relay outputs for industrial automation control.
Q3、Which drive series is compatible with the 1336-MCB-SP1?
The board is mainly compatible with Allen-Bradley 1336 Plus and 1336S adjustable frequency AC drives, especially Frame B through H drive configurations.
Q4、Is the 1336-MCB-SP1 still in production?
No. The 1336-MCB-SP1 and the related 1336S drive family have been discontinued by the manufacturer. However, replacement units and surplus inventory are still available through industrial automation spare parts suppliers.
Q5、What are the advantages of the Allen Bradley 1336-MCB-SP1?
The module offers reliable motor drive control, stable analog and digital signal processing, diagnostic capabilities, flexible communication support, and durable industrial-grade construction suitable for harsh operating environments. It also supports easy integration with optional communication and interface modules.
