Allen-Bradley 1305-AA08A Adjustable Frequency AC Drive

Allen-Bradley 1305-AA08A
Allen-Bradley 1305-AA08A
Allen-Bradley 1305-AA08A

Allen-Bradley 1305-AA08A Adjustable Frequency AC Drive

Calculate shipping
Quotation Request




AC DRIVE / BULLETIN 1305
1305-AA08A

Adjustable Frequency
AC Drive
A compact 200–230 V class drive for adjustable-speed three-phase motor applications.
1305 SERIES
THREE NUMBERS TO CHECK
POWER 1.5 kW / 2 HP
CURRENT 8.0 A
FREQUENCY 0–400 Hz programmable
Input class: 200/230 V AC, 50/60 Hz
Operational range: 180–265 V

AMIKON
Automation parts,
ready to source.
We have a wide range of brands and products for various industries, we provide services to tens of thousands of customers around the world.
✉   Miya zheng  sales@amikon.cn ☎   86-18020776792


ALLEN-BRADLEY / BULLETIN 1305

1305-AA08A

Adjustable Frequency AC Drive


A 2 HP / 1.5 kW Bulletin 1305 drive in the 200–230 V class, with an 8 A output rating and support for either single-phase or three-phase input within the applicable rating conditions.


MOTOR CLASS
2 HP
1.5 kW
OUTPUT
8.0 A
rated output current
INPUT CLASS
200–230 V
50/60 Hz
PRODUCT ARCHITECTURE

A 1305 Drive Built Around a 2 HP Class

08
AA08 rating


The AA08 position in the 1305 family corresponds to the 1.5 kW / 2 HP class and an 8.0 A output rating for the 200–230 V family.
OUTPUT VOLTAGE
0 V to input voltage
adjustable output range
OUTPUT FREQUENCY
0.00–400.00 Hz
programmable frequency range
INPUT RANGE
180–265 V
operational voltage range
EFFICIENCY
≈97.5%
typical operating value
FAMILY COMPARISON

How AA08 Differs Inside the 1305 Family

1305-AA08A 200–230 V class 2 HP / 1.5 kW 8.0 A output
1305-AA04A 200–230 V class 1 HP / 0.75 kW 4.5 A output
1305-AA12A 200–230 V class 3 HP / 2.2 kW 12 A output at 200 V
1305-BA Series 380–460 V class Different voltage family Separate motor-rating selection
AA08 1.5 kW 8 A 1305 FAMILY
AMIKON / INDUSTRIAL AUTOMATION STOCK

Amikon's Large Stock Is the Core of Our Supply


AMIKON'S LARGE STOCK IS THE CORE OF OUR SUPPLY.

400,000+ ELECTRONIC PRODUCTS
PLC · HMI · DRIVES · SERVO · CNC · IPC · PG

NEW OR OUT OF PRODUCTION — FROM SMALL MODULES TO COMPLETE CONFIGURATIONS, WE KEEP DIFFERENT GENERATIONS OF INDUSTRIAL PRODUCTS IN VIEW.
Strategic purchasing is guided by market demand, technology development and customer requirements. When an item is unavailable, our preferred supplier network can be searched for you.
CONTACT AMIKON

Request 1305-AA08A

SALES MANAGER
Miya zheng
EMAIL
sales@amikon.cn
PHONE / WHATSAPP
86-18020776792
PURCHASING QUESTIONS

Before Selecting 1305-AA08A

Does 1305-AA08A represent the same power class as 1305-AA04A?

No. AA08 is 2 HP / 1.5 kW with 8.0 A output, while AA04 is 1 HP / 0.75 kW with 4.5 A output in the same 200–230 V family.
Can 1305-AA08A be selected only by matching the motor horsepower?

No. Voltage class, phase arrangement, output current and the actual motor full-load current also need to be checked.
What makes 1305-AA08A different from a BA-series 1305 drive?

The AA08 belongs to the 200–230 V family, whereas BA-series drives are selected for the 380–460 V class.
What should be checked if 1305-AA08A is used near its upper operating temperature?

Thermal conditions and the applicable current derating requirements should be reviewed, especially around the 50 °C maximum ambient condition.
Why should the wiring arrangement be checked when replacing 1305-AA08A?

The AA08 belongs to the 1305 Frames B/C group, with defined locations for control I/O, optional brake, filter input, motor output and grounding.
RETURN / REPLACEMENT: Please contact us within 7 days after receiving the item. Returned items should be in original condition with the specific reason for return. A return or replacement will be arranged after receipt. Shipping costs are the buyer's responsibility.
