CENTRAL HUMAN-MACHINE INTERFACE
MV570
ABB 1TNA928300R0001
A 10.4-inch industrial touch-panel HMI designed for ABB MNS Digital low-voltage switchgear applications. MV570 combines an industrial display, touch operation, Ethernet connectivity and USB interfaces in a panel-mounted operator interface.
10.4" TFT / LED 800 × 600 24 VDC
|
|
|
DISPLAY
10.4"
4:3 colour TFT / LED backlight
|
RESOLUTION
800 × 600
Maximum display resolution
|
POWER
24 VDC
8 W typical consumption
|
PROTECTION
IP65
Front-panel protection
|
|
PRODUCT ARCHITECTURE
Built Around the Operator
MV570 is a RISC-based industrial tablet computer with a pre-installed Android operating system. The unit uses a projected-capacitive touch panel and provides dedicated industrial communication interfaces.
Operator interface role
With SmiSView installed, MV570 can serve as a monitoring and operating interface for MC510 and related modules within the applicable MNS Digital project environment. |
|
|
MV570
Central HMI / operator interface
10.4" touch display
Android platform Ethernet + USB SmiSView operator environment |
→ |
SmiSView
Visualization and project operation
Monitoring views
Project configuration Online operation User-oriented interface |
→ |
Connected Modules
MNS Digital equipment
MC510 and related modules
Network communication Operating status Alarms and process values |
| SYSTEM ROLE | Operator visualization | Project operation | Industrial Ethernet interface |
|
OPERATOR FUNCTIONS
Designed for Industrial Interaction
In the MNS Digital environment, MV570 can provide access to operational views and project functions through the SmiSView environment. Depending on user access and the connected system configuration, the interface can be used for monitoring, parameterization, control, maintenance and project management.
|
|
|
01
Power
Confirm a suitable 24 VDC supply and correct polarity before energizing. |
02
Panel Fit
Use the specified panel cut-out and sealing arrangement to maintain the intended front-panel protection. |
03
Network
Check Ethernet connection, addressing and the connected MNS Digital project configuration. |
04
Environment
Operating range is 0°C to 55°C; humidity is 5% to 90% non-condensing. |
|
DIRECT SALES SUPPORT
Need MV570?
Send the complete model and quantity for a quotation. For replacement projects, including the installed system and interface requirements can help speed up model verification.
|
|
||||
| Can MV570 1TNA928300R0001 replace another MV570 directly?
A direct replacement should not be assumed from the MV570 name alone. The complete 1TNA928300R0001 identity, hardware execution, software/project configuration, panel installation and connected MNS Digital equipment should be checked before replacement.
|
| Does MV570 1TNA928300R0001 support Ethernet communication?
Yes. The MV570 specification provides one 10/100/1000 Mbps Ethernet port with PoE capability. The Ethernet connection is used within the applicable MNS Digital system environment.
|
| What should be checked when ordering MV570 1TNA928300R0001 for an existing panel?
Confirm the complete ordering number, installed project configuration, software environment, power arrangement, Ethernet settings and mechanical panel installation before placing a replacement order.
|
| Is the MV570 1TNA928300R0001 suitable for outdoor installation?
The unit is specified for industrial environments and has IP65 protection from the front panel, but the operating conditions must still remain within the specified temperature, humidity and installation requirements. The manufacturer also advises avoiding prolonged direct sunlight and corrosive chemical exposure.
|
| Can MV570 1TNA928300R0001 be used without checking the connected MNS Digital equipment?
For an installed-system replacement, compatibility should be checked against the connected MNS Digital equipment and project configuration. MV570 is intended to operate as an interface for the applicable system environment rather than as an independent replacement for the connected control modules.
|
|
AFTER-SALES
Return / Replacement
|
• Please contact us within 7 days if you have any question after you receiving the items.
• The returned items has to be in its original condition, with a specific reason for the return. We will issue a return or replacement for your order after we received the returns.
• The buyer is responsible for all the shipping cost incurred.
|
