Product detailed parameters
|
parameter |
value |
|
Order code |
ECHAM 086369-001 |
|
Output |
24 V dc, 5 A, 120 W |
|
Input range |
85-264 V ac / 90-375 V dc, 47-63 Hz |
|
Efficiency / PFC |
91 % typ., active PFC >0.95 |
|
Ripple & noise |
<50 mV pk-pk (20 MHz BW) |
|
Hold-up time |
30 ms @ 115 V ac full load |
|
Isolation |
3 kV ac input-output, 500 V output-PE |
|
Parallel function |
Integrated OR-ing diode, current-share ±5 % |
ECHAM 086369-001 Features
|
●24 V dc / 5 A slim supply – 120 W with ±1 % regulation and <50 mV ripple keeps drives and logic noise-free. |
|
●Push-in terminals – tool-less wiring accepts 0.2-4 mm² ferruled wire, cutting panel build time by 30 %. |
|
●Harsh-duty rated – -25 °C…+70 °C, 4 kV surge, 5 g vibration; UL 508, ABS, CE, RoHS-10 compliant. |
If you have any questions, please contact us.
