| General Information | |
| Product ID: | ABB DSDX454 5716075-AT |
| Input Voltage: | 24V DC |
| Power Consumption: | Maximum of 10W |
| Ordering | |
| Protection Rating： | IP20 |
| weight： | 2.76kg |
| Product Net Depth / Length: |
235mm |
| Product Net Height: |
90mm |
| Product Net Width: |
220mm |
| 1. Purpose and Functionality: | |
| I/O Expansion： | Increases the system's input and output capacity, allowing for the connection of more field devices such as sensors and actuators. |
| Remote Operation: | Supports distributed placement of I/O modules, enabling control over processes spread across large areas or multiple locations. |
| System Integration: | Ensures compatibility and smooth communication with existing Advant Controller systems, supporting various industrial communication protocols. |
| 2. Key Attributes: | |
| Operating Temperature Range： | -20°C to +55°C |
| Storage Temperature Range： | -40°C to +70°C |
You May Like
| 240128A 740545B | FBM207C P0917GY | ECT/4-20MA/2X4-20MA/24DC |
| E3H020 | FBM204 P0914SY | EPRO PR6423/000-031 |
| E3M071 | 51304912-100 | EPRO PR6424/000-030 |
| E3L020 | 51402453-200 | 07DI92 |
| FBM205 P0914XG | FPS400-24 P0922YU | TRICONEX 3504E |
| FBM203 P0914SV | 51402645-200 | ME203/CNW |
| FBM202/P0926EQ | 51305074-100 | LYD050A |
| CNT204/H | P0961FR | 6ES5466-8MC11 |
| EM203 | FBM224 P0926GG | TRICONEX 3007 |
| 1C31129G03 | 51402083-200 | TRICONEX 3636R |
| E3X102 | 51196653-100 | 330103-00-02-10-02-00 |
| B3Q565 | FBM206 P0916CQ | KJ4001X1-BE1 |
Please contact us and look forward to our cooperation!
ABB 07KT92 GJR5250500R0202 is 07 KT 92 Central Unit - 90 Series 24 VDC Power Supply CPU - 14 K FLASH EPROM twelve 24 VDC inputs Eight 24 VDC/ 0.5A transistor outputs 4 analogue inputs 12 bits resolution 2 analogue output 12 bits resolution 2 programmable RS 232 port RS 485 system The Dimensions is 24 cm x 13.7 cm x 8.5 cm, and the weight is 1 lbs 10.1 oz (0.64 kg ).
ABB DSPC172H 5731001-MP Master CPU Module DSPC172H ABB Master CPU Module Model Type: 57310001-MP/2 DSPC 172H ABB Master CPU Module, article number 57310001-MP/2. Firmware prom sub-modules. Dimensions: 5.1 cm x 25.4 cm x 25.4 cm Weight: 2 lbs 8.0 oz (1.1kg ) Series: ABB Master series module
ABB DSQC201 YB560103-AB Robot Module DSQC 201 Robot Module Model Type: YB560103-AB Dimensions: 15.2 cm x 2.5 cm x 22.9 cm Weight: 0 lbs 6.0 oz (0.2kg ) Series: ABB Robots robotics series module
ABB DSQC541 PCB Backplane Controller Card DSQC541 DSQC 541 Backplane Card module Model Type: DSQC541 DSQC 541 Input Voltage: 24V DC Operating Temperature: 0°C to 45°C Storage Temperature: -25°C to 70°C Dimensions: 19.2 cm x 12.5 cm x 22.9 cm Weight: 0 lbs 6.0 oz (0.220 kg ) Series: ABB Robots robotics series module
ABB DSQC608 3HAC12934-1 Robotics Power Supply Module DSQC608 3HAC12934-1 DSQC 608 Model Type: 3HAC12934-1 Input Voltage: 24V DC Operating Temperature: 0°C to 45°C Dimensions: 7.1x13.5x18.5cm Weight: 1.380 kg Series: ABB Robots robotics IRC5 Single series module
ABB DSQC643 3HAC024488-001/01 Controller Panel Board DSQC 643 DSQC643 3HAC024488-001/01 Model Type: 3HAC024488-001/01 Input Voltage: 24V DC Operating Temperature: 0°C to 45°C ROBOTICS FOR IRC5 CABINET WITH FLAT DOORS Dimensions: 28x20.3x2.7cm Weight: 0.400 kg Series: ABB Robots robotics controller IRC5 Single series module
ABB IMDSO14 Digital Output Slave Module Parts Type: Digital Output Slave Model Type: Bailey Infi 90 IMDSO14 Digital Output Slave, 16-Channel Open Collector, Power Requirements +5 VDC, 370 mA Dimensions: 17.8 cm x 5.1 cm x 33.0 cm Weight: 0.200 kg Series: ABB Bailey Infi 90, ABB Bailey Infi 90 and Net 90
ABB MB510 3BSE002540R1 Program Card Interface Module Parts Type: MB510 Program Card Interface Model Type: 3BSE002540R1 Country of Origin: Sweden Dimensions: 2.2x17x10.2cm Weight: 0.1400 kg Series: Advant OCS with Master, Advant Controller 450RMC
