ABB DSDX452 5716075-P Digital Output Module

ABB DSDX452 5716075-P Digital Output Module

⇒ Model Number PHBAIN2200C100 AIN-220
⇒ Country of Origin:  Sweden
⇒ Description: Digital Output Module
⇒ Shipping Worldwide by DHL /Fedex /TNT / UPS
⇒ Weight

2.84KG

⇒ Dimensions

23.7x21.8x9cm



Mobile :86-18020776792        Email : sales@amikon.cn

What’s app:86-18020776792  Skpye:miyazheng520

Technical Specifications

Product Type:  Digital Output Module
Part Number:  DSDX452
Manufacturer:  ABB
Series:  DSD (Distributed Control System)
Input Voltage Range:  Typically 24 V DC
Number of Outputs:  8
Output Type:  Transistor output
Output Current per Channel:  0.5 A
Total Output Current:  4 A
Response Time:  Fast switching (typically < 1 ms)
Operating Temperature Range:
-20 °C to +60 °C
Humidity:
5% to 95% (non-condensing)

Additional Features

LED Status Indicators: Each output channel is equipped with LED indicators to provide real-time status feedback, allowing for easy monitoring of the output conditions.
Short-Circuit Protection: The module includes short-circuit protection for each output channel, ensuring safety and preventing damage to the module and connected devices in case of electrical faults.
Galvanic Isolation: Provides galvanic isolation between the output channels and the internal circuitry, enhancing system reliability and reducing the risk of interference.
Wide Operating Temperature Range: Designed to operate effectively in harsh environments, with a temperature range from -20 °C to +60 °C, suitable for various industrial applications.
High Switching Frequency: Capable of fast switching times (typically < 1 ms), making it suitable for applications that require rapid response times.
DIN Rail Mountable: Designed for easy installation on standard DIN rails, facilitating integration into control cabinets and panels.

If you want to more details,please contact me without hesitate. Email:sales@amikon.cn


Technical Issues and Solutions

1. Issue: Module Not Responding or Failing to Power On

Solution:

  • Check the power supply connections to ensure the module is receiving the correct voltage (typically 24 V DC).

2. Issue: Inconsistent or No Output Signal

Solution:

  • Verify that the output channels are properly configured and programmed in the control system.

3. Issue: LED Indicators Not Lighting Up

Solution:

  • Ensure that the module is powered on and that the power supply is functioning correctly.

4. Issue: Communication Failures with the DCS

Solution:

  • Verify that the communication settings (e.g., baud rate, address) are correctly configured in both the module and the DCS.

5. Issue: Overheating of the Module

Solution:

  • Ensure there is adequate ventilation around the module to prevent heat buildup.
