| General Information | |
| Product ID: | 3BHT300026R1 |
| ABB Type Designation: | DI651 |
| Catalog Description: | DI651 Digital Input 32ch, 48VDC isolated |
| Long Description: | DI651 Digital Input 32Ch |
| Technical Information: | S600 I/O Digital Input Module. 32 channels, 48 V d.c., opto-isolated in four groups, sequence of event or pulse catching capability |
| Product Type: | Digital Input Module | Input Channels: | 16 channels |
| Input Type: | 24 V DC | Low-level input: | 0 to 5 V DC |
| High-level input: | 15 to 30 V DC | Input Current: | Typically < 10 mA per input |
| Isolation: | 500 V AC | Typical: |
1 ms |
| 1.What is the ABB DI651 3BHT300026R1? |
| The ABB DI651 3BHT300026R1 is a digital input module designed for use with ABB's control systems, such as the AC 800M or 800xA. It provides 16 digital input channels for monitoring binary signals. |
| 2.What is the input voltage range for the DI651? |
| The DI651 module typically accepts input voltages ranging from 15 to 30 V DC for a high-level signal (logic '1') and 0 to 5 V DC for a low-level signal (logic '0'). |
| 3.How many input channels does the DI651 have? |
| The DI651 module has 16 digital input channels. |
| 4.What is the response time of the DI651 module? |
| The typical response time is 1 ms, with a maximum of 2 ms. |
| 5.What is the operating temperature range for the DI651? |
| The module operates within a temperature range of 0°C to 55°C (32°F to 131°F). For storage, the range is -40°C to 70°C (-40°F to 158°F). |
