ABB CI810B 3BSE020520R1 Communication Interface

ABB CI810B 3BSE020520R1 Communication Interface

ABB AUTOMATION
CI810B
3BSE020520R1

AF100 FIELDBUS
Communication interface for ABB control architecture.
NETWORK INTERFACE
COMMUNICATION ARCHITECTURE
AF100 Dual-Path Interface
AF100 FIELD COMMUNICATION
MODEM A
AF100
Twisted Pair
↔
MODEM B
AF100
Twisted Pair
Two AF100 twisted-pair modem connections
SYSTEM SOFTWARE
V1.5
Basic software loaded
BUS TERMINATION
TB807
Modulebus terminator


CONTACT SALES
Sales Manager: Miya Zheng
✉ sales@amikon.cn ☎ +86 180 2077 6792
◆  ABB S800 I/O / AF100
CI810B
3BSE020520R1

Communication interface for an ABB S800 I/O station on Advant Fieldbus 100, providing the connection between the AF100 segment and the local ModuleBus.

2 AF100
twisted-pair connections
S800 I/O
station interface
TB807
ModuleBus terminator supplied


◆  Sales manager: Miya zheng ✉  sales@amikon.cn ☎  86-18020776792
◆  01 / NETWORK IDENTITY
Trace the communication path before replacement
AF100
Fieldbus segment
→ CI810B
Network-to-station interface
→ ModuleBus
Local S800 I/O path
Buyer check
Address, cable position and termination
◆  02 / TECHNICAL MATCH
Specification ledger
Article number 3BSE020520R1 Designation CI810B
Network Advant Fieldbus 100 Local I/O ABB S800 I/O
Fieldbus ports Two twisted-pair AF100 connections Included items Power connector and TB807 terminator
Environmental class ISA-S71.04 level G3 Commissioning focus Node address, segment wiring and station diagnostics
◆  03 / RELATED HARDWARE
Select by system responsibility
CI810B
Main item

AF100 communication interface for the S800 I/O station.

TB807
Required companion

ModuleBus terminator used at the end of the local bus.

CI840 / CI840A
Different architecture

PROFIBUS DP-V1 communication interfaces; not an AF100 substitute.

◆  AMIKON LIMITED
Keep the station visible, connected and supported

We support industrial automation users with multi-brand PLC, DCS, safety, drive, turbine-control and condition-monitoring components.

◆  Experienced multilingual support
◆  Broad spare-parts coverage
◆  International response network

◆  05 / BUYER FAQ
Questions that protect network compatibility
Q1 What must match before buying ABB CI810B 3BSE020520R1?
Confirm the complete article number, AF100 segment arrangement, node addressing, S800 station layout, power connection and the required TB807 ModuleBus terminator.
Q2 Can ABB CI810B 3BSE020520R1 be replaced by a CI810 without checking the revision?
Do not assume a direct swap. Compare the B revision, installed system software, station configuration, connector set and commissioning data before removal.
Q3 Which network details should be recorded before replacing ABB CI810B 3BSE020520R1?
Record both AF100 cable positions, polarity, shielding, node address, segment termination, neighboring stations and diagnostic indications.
Q4 What should be inspected when ABB CI810B 3BSE020520R1 arrives?
Inspect the housing, two AF100 connectors, power-supply connector, ModuleBus interface, TB807 terminator, latches and full product marking.
Q5 What should be tested after ABB CI810B 3BSE020520R1 installation?
Verify power-up status, node communication, both AF100 paths, ModuleBus communication, I/O station visibility and controller diagnostics before returning the process to service.
◆  Sales manager: Miya zheng ✉  sales@amikon.cn ☎  86-18020776792
◆  06 / MORE AUTOMATION MODELS
Available across multiple automation platforms
X20CP3585 AB7000-C 5AP1130.185C-000 3CP340.60-2 BWU3274
X67SM2436 UE43-3MF2D3 RF3332 A3C40173228 F01U033343
NBG-12LX MRI-M500S 3UG4614-1BR20 KJ3208X1-BA2 KJ3206X1-BA2
KL2001X1-BC1 KJ3221X1-BK1 KC4011X1-BP1 KC3010X1-BA2 KL2101X1-BA1
31000-16-05-00-033-03-02 31000-16-10-15-040-03-02 190501-21-00-01 330702-00-30-10-01-05 31000-28-10-00-190-02-02
31000-26-05-20-041-01-024 330101-00-81-10-02-05 21504-036-068-10-02 SNAT7600 99-5835-01
ACS550-01-023A-4 IC200ALG630 85853637-001 6SL3131-7TE21-6AA3 6SE6440-2UD22-2BA1
6RA7031-6DV62-0 6SN1145-1BB00-0DA1 6SL3362-0AG00-0AA1 6SL3111-4VE21-6EC1 ICX35-HWC-E
OPTO22 SNAP-LCM4 MP530 D530 DC578AV 50080121-001 ACM-000 DX8210-4100 IMX-M 102G
ABB 001-1004-03 VP-T537 HVBNET16TO ESP-00 TXR-320
◆  07 / AFTER-DELIVERY SUPPORT
01   Contact within 7 days
Send the order details, photographs and a clear description of the concern.
02   Keep the item complete
Approved returns must retain the original condition, packaging and supplied accessories.
03   Inspection and resolution
Return or replacement follows receipt and inspection; return shipping remains the buyer's responsibility.
◆  Sales manager: Miya zheng ✉  sales@amikon.cn ☎  86-18020776792
