ABB ROBOTICS · MOTION COMPONENT
3HAC038405-003Motor Axis 6 incl. Pinion
A dedicated ABB robotic motion component associated with axis 6 drive movement. The motor-and-pinion configuration is intended for precise mechanical motion within an ABB robotic system.
|
|
|
DELIVERY
3–5 Days
|
WARRANTY
12 Months
|
PACKAGING
New
|
PART NUMBER
3HAC038405-003
|
|
01
Axis 6 MotionAxis 6 is part of the articulated robot motion chain and contributes to wrist orientation and controlled tool movement. |
02
Motor + PinionThe identified assembly combines a motor with a pinion, providing the mechanical drive interface required for the associated robotic axis. |
03
Maintenance FocusWhen an axis motor becomes unavailable, unstable or unable to complete commanded motion, replacement of the relevant motor assembly may become part of corrective maintenance. |
|
02 · TECHNICAL FOCUS
A Motion Component
|
|
|
APPLICATION
Robotic AutomationABB articulated robots are used across material handling, machine tending, welding, cutting, assembly, inspection and other automated production tasks. |
MAINTENANCE SIGNAL
Unstable Axis MotionA motor-related issue can become relevant when the affected axis cannot execute commanded movement normally, develops abnormal motion behaviour, or requires corrective maintenance. |
PRODUCTION IMPACT
Avoid Extended DowntimeIf the affected robot is part of an automated production cell, unavailable axis motion can interrupt the robot cycle and delay downstream production activities. |
 AMIKON TEAM
|
 AMIKON WAREHOUSE
|
|
04 · AMIKON
Millions of Industrial Parts.
|
|
|
Q1
What role does 3HAC038405-003 play in an ABB robot?
The part is identified as a motor for axis 6 with a pinion. Axis 6 forms part of the articulated robot motion system and contributes to wrist-side positioning and orientation.
|
Q2
Why is the pinion relevant to this motor assembly?
The pinion provides the mechanical transmission element associated with the motor assembly, allowing motor rotation to be transferred into the relevant axis drive mechanism.
|
|
Q3
When might a replacement motor for axis 6 become necessary?
A replacement may become relevant during corrective maintenance when the affected axis no longer performs its commanded motion correctly or the motor assembly has been identified for replacement during service.
|
Q4
What production activities can depend on accurate robot axis movement?
ABB articulated robots are used for tasks such as material handling, machine tending, welding, cutting, assembly, testing and inspection. Stable axis movement supports the robot cycle in these applications.
|
|
Q5
What should be checked when requesting 3HAC038405-003?
Confirm the complete part number, required quantity, destination, required date and the machine or robotic system where the component will be installed. These details help the sales team handle the inquiry accurately.
|
|
|
