ABB ROBOTICS • MOTOR ASSEMBLY
3HAC034647-003
Motor with Pinion
A Type A motor assembly for Axis 3 applications in the ABB IRB 4600 robot family. Designed around the mechanical drive requirements of the specified robot axis.
|
PRODUCT ID
3HAC034647-003
|
|
POWER
2238 W
|
TORQUE
4.5 Nm
|
AXIS
Axis 3
|
DESIGN
Motor + Pinion
|
|
01 / CORE SPECIFICATIONS
Built Around Axis 3
|
02 / ROBOT CONFIGURATION
IRB 4600 Compatibility
The ABB spare-parts configuration identifies this motor for Axis 3, Type A across the following IRB 4600 configurations:
For replacement work, confirm the complete robot configuration and the exact part number before ordering.
|
|
03 / APPLICATION
When Axis 3 Performance Matters
Within an IRB 4600 installation, the Axis 3 motor contributes to the controlled movement of the robot arm. When the motor, pinion or associated drive train can no longer provide the expected motion, the robot may show abnormal movement, positioning problems or an inability to complete the commanded cycle.
|
SERVICE PRIORITY
Minimize Production Interruption
A failed Axis 3 motor can interrupt robotic movement and affect production cycles. Having the correct replacement part identified in advance helps reduce troubleshooting and recovery time.
|
|
DELIVERY
3–5 Days
|
WARRANTY
12 Months
|
PACKAGING
Brand New
|
SUPPORT
Fast Response
|
|
