ABB 3BHL000392R0101 5SHX1060H0001/3BHB003230R0101 5SXE05-0152 Drive Control Unit
|
Contact info |
|
|
Sales manager: |
Miya Zheng |
|
Mobile: |
|
|
Email: |
|
|
Whatsapp: |
|
descriptions |
|
Device type: asymmetric IGCT |
|
Repetitive peak off-state voltage VDRM: 4.5 kV |
|
Average on-state current ITAV: 630 A @ 60 Hz, 85 °C case |
|
Surge on-state current ITSM: 6.0 kA |
|
Turn-off current ITGQ: 1.0 kA |
|
Gate-cathode voltage VGK: ±20 V |
|
Isolation voltage: 3 kV AC (1 min) base-plate to heatsink |
|
Thermal resistance Rth(j-c): 0.065 K/W |
|
Package outline: 140 mm × 73 mm × 26 mm |
|
Summary |
|
The ABB 3BHL000392R0101 5SHX1060H0001 / 3BHB003230R0101 5SXE05-0152 is a 4.5 kV / 630 A asymmetric IGCT that acts as the main switching device in medium-voltage drives up to 3 MVA. Its 1 kA turn-off capability and 6 kA surge rating let designers eliminate bulky snubber networks, while the 0.065 K/W thermal resistance keeps heatsinks small even at 60 Hz switching. Drop-in compatible with existing ABB ACS 6000 power stacks, it gives OEMs a quick way to boost line voltage or replace aging GTOs without re-wiring the cabinet. |
|
