PROTECTION & CONTROL IED / BINARY INPUT
1MRK000508-BDR06
BIM 16-Channel Binary Input Module
FIELD SIGNAL ACQUISITION
The BIM architecture provides sixteen binary input channels for monitoring discrete field states in compatible ABB protection and control IED configurations. The 1MRK000508-BD designation corresponds to the RL110 input class, with 110–125 V DC field input and 50 mA input rating.
|
MODULE PROFILE
BIM / Binary Input Module
ABB protection and control IED architecture
SIGNAL INTERFACE
RL110 · 110–125 VDC · 50 mA
SYSTEM ROLE
Discrete status acquisition for compatible protection and control configurations.
|
|
01 / TECHNICAL CORE
Electrical Interface
|
|
|
SIGNAL ARCHITECTURE
Sixteen-channel binary acquisition
The module is intended to receive discrete DC field states through its sixteen binary input channels. For replacement work, the installed voltage class, channel allocation, terminal arrangement and receiving IED configuration should remain matched to the existing application.
|
APPLICATION CONTEXT
Protection & Control IED Integration
Within compatible ABB protection and control IED configurations, BIM modules provide the discrete signal interface between field circuits and the relay/control application.
REPLACEMENT CHECKPOINTS
• Verify the complete 1MRK000508-BDR06 designation.
• Confirm the RL110 / 110–125 VDC input class.
• Match the receiving IED rack and module position.
• Preserve channel assignment and field wiring.
|
|
02 / FAMILY MAP
Related BIM Variants
The 1MRK000508 family uses different input classes for different DC field-voltage ranges. The electrical class is therefore a critical selection point.
|
WHY THE VARIANT MATTERS
These variants share the BIM 16-input architecture but differ in field-voltage class. A voltage-compatible module should be selected according to the installed relay configuration rather than by physical appearance alone.
|
|
03 / DIRECT SUPPORT
Need an exact
1MRK000508-BDR06? For quotation and replacement verification, provide the complete part number, required quantity, destination and required delivery date.
|
|
||||
|
1. Does 1MRK000508-BDR06 match the RL110 input class?
The 1MRK000508-BD family is the RL110 version of the BIM, specified for 110–125 V DC binary input circuits with a 50 mA input rating. The complete BDR06 execution should be matched to the installed protection IED configuration.
2. Can 1MRK000508-BDR06 replace an RL220 BIM?
Not as a voltage-class substitution. The BIM family contains separate RL110 and RL220 variants. The RL110 1MRK000508-BD is specified for 110–125 VDC, while 1MRK000508-CD is the 220–250 VDC variant. The receiving IED configuration must determine the correct choice.
3. What should be checked before ordering 1MRK000508-BDR06?
Check the complete ordering designation, installed BIM voltage class, receiving IED type, rack position, terminal arrangement and the existing channel assignment. A physical fit alone is not sufficient for electrical replacement.
|
4. How many field states can 1MRK000508-BDR06 acquire?
The BIM architecture provides 16 binary input channels. Each channel is intended for a discrete field signal within the applicable input class and compatible IED configuration.
5. Why does 1MRK000508-BDR06 need exact variant verification?
The 1MRK000508 family contains multiple BIM electrical variants. RL24, RL48, RL110 and RL220 versions use different field-voltage ranges, so the complete part designation and installed relay configuration should be checked before replacement.
PURCHASING NOTE
For an exact quotation, send the complete model number together with quantity, destination and required date.
|
|
05 / ORDER ASSURANCE
Return & Replacement
For any post-delivery concern, please follow the conditions below so the case can be processed efficiently.
|
01 Please contact us within 7 days if you have any question after you receiving the items.
02 The returned items has to be in its original condition, with a specific reason for the return. We will issue a return or replacement for your order after we receive the returns.
03 The buyer is responsible for all the shipping cost incurred.
|
|
