Probe Type 8 mm High-Performance Eddy Current Probe Length 0.5 m Linear Range 2.0 mm (80 mils) Output Signal 4-20 mA Power Supply -18 to -26 VDC Cable Length 5.0 m Operating Temperature -35°C to +177°C (probe)
Probe Length 0.5 m Linear Range 4.0 mm (160 mils) Output Signal -2 to -18 VDC Power Supply -24 VDC Cable Length 7.0 m Operating Temperature -35°C to +120°C (probe)
Input Signals 2 independent Keyphasor inputs Input Range 0.5–150 Vrms (sine/triangle) Frequency Range 1–20,000 RPM Output Signals 4 buffered TTL/24 VDC pulses Power Consumption 5.6 W Operating Temperature 0°C to +65°C
Sensitivity 20 mV/mm/s (typical) Frequency Range 4.5–1000 Hz Measurement Range 0–20 mm/s RMS Power Supply 18–30 VDC, 2-wire Output Signal 4–20 mA (velocity proportional) Operating Temperature -50°C to +100°C
Probe Length 0.5 m Linear Range 2.0 mm (80 mils) Output Signal 4-20 mA Power Supply -18 to -26 VDC Cable Length 10 m Operating Temperature -35°C to +350°C (probe)
