| General Information | |
| Product ID: | ABB DPW02 |
| Port Type: | Ethernet port module, providing multiple Ethernet connection interfaces. |
| Port Quantity: | The specific number of ports depends on the robot controller configuration, typically including service ports (X2), LAN ports (X3, X4, X5), and WAN ports (X6). |
| Ordering | |
| Port Speed: | Spupports auto-negotiation for 10/100/1000 Mbps Ethernet speeds. |
| Port Configuration: | Ports can be configured as different network interfaces such as LAN, WAN, etc. |
| Product Net Depth / Length: |
75mm |
| Product Net Height: |
115mm |
| Product Net Width: |
130mm |
| 1. Purpose and Functionality: | |
| Ethernet Communication Interface: | The DPW02 provides Ethernet communication capabilities to ABB robot controllers, enabling seamless network connectivity for controlling and monitoring industrial robots. |
| Multiple Network Ports: | The module features multiple Ethernet ports, which can be used for different purposes, such as LAN (Local Area Network) and WAN (Wide Area Network) connections. These ports ensure flexible network configurations for industrial communication. |
| Support for High-Speed Data Transmission: | The module supports auto-negotiation for Ethernet speeds up to 1000 Mbps (Gigabit Ethernet), ensuring high-speed and reliable data transmission between the robot controller and other connected devices. |
| 2. Key Attributes: | |
| Power Supply： | The module is powered directly by the robot controller, eliminating the need for a separate power supply. This simplifies the system design and installation. |
| Temperature Range: | temperature range of 0°C to 45°C |
