Honeywell MLI‐DR60SU Logic Controller

Honeywell MLI‐DR60SU Logic Controller

HONEYWELL · MASTERLOGIC-50
MLI-DR60SU
SUPPLY VOLTAGE
100–240V
AC Input
INPUT CHANNELS
36
DC Digital Input Points

OUTPUT CHANNELS
24
Relay Output Points

◇ AC Power Supply ▰ 36-Point DC Input ⌁ 24-Point Relay Output
SALES MANAGER
Miya Zheng
✉ EMAIL SALES ☏ WHATSAPP
HONEYWELL / MASTERLOGIC 50 / SU OverviewConsoleExpansionFAQ
STANDARD SU MAIN UNIT / 100-240 VAC / MIXED DIGITAL I/O
MLI-DR60SU
Sixty onboard points with scalable MasterLogic control

A standard SU controller combining a 16-bit CPU, AC power section, thirty-six 24 VDC inputs, twenty-four relay outputs and built-in serial communication.

REQUEST SYSTEM CHECK
36
DIGITAL INPUTS

24 VDC
24
RELAY OUTPUTS

4 / COM
CONTROL CONSOLE
CPU, I/O and communication in one main unit
CPU
94 ns basic step
200 kB program
Flash program backup
INPUT
20.4-28.8 VDC range
19 V / 3 mA ON
1-100 ms filter
OUTPUT
24 relay points
2 A resistive load
4 points/common
LINK
RS-232C
RS-485
2 option positions
LOCAL 60
36 DI + 24 relay outputs
EXPANSION ENVELOPE
284 I/O
Up to 7 expansion modules
SERIAL
Programming and device links

AMIKON / 2005-2026
Twenty years of industrial automation supply

Amikon supports global manufacturers and system integrators with PLC, HMI, DCS, panel-control, industrial-computing and drive components.

12-month warranty
Responsive quotation support
International delivery coordination


PROCUREMENT CONSOLE
Five MLI-DR60SU decisions that matter
01 Is MLI-DR60SU a passive I/O module? No. It is the complete SU CPU, AC power and mixed-I/O main unit.
02 Can its relays directly drive every contactor? Check coil inrush, inductive rating, suppression and common current; the 2 A resistive rating is not a coil rating.
03 What expansion limit applies? Plan for up to seven expansion modules and 284 total I/O while checking power and addressing.
04 How should replacement be prepared? Back up the program and operating data; record option boards, serial settings, expansion order and wiring.
05 What should accompany an inquiry? Provide the complete label, AC supply, option boards, expansion modules, backup status and terminal photographs.
