Honeywell MLC-DR32H Digital Output Module

Honeywell MLC-DR32H Digital Output Module

HONEYWELL / MASTERLOGIC 50
MLC-DR32H
PLC TYPE
BLOCK TYPE
01   DIGITAL INPUT
16 Points
DC 24V input
02   RELAY OUTPUT
16 Points
Relay output · 4 points / COM
03   PROCESSING SPEED
83 ns
Basic instruction / step
International Delivery on the Day Quick Response Support Intercontinental Cooperation Network
SALES MANAGER
Miya Zheng
AMIKON Limited
✉ Email: sales@amikon.cn WhatsApp: +86 180 2077 6792 Contact QR code
HONEYWELL / COMPACT CONTROL OVERVIEWCPU + I/OFITFAQ
■ MASTERLOGIC 50 / COMPACT CPU
MLC-DR32H
AC-Powered Controller with Integrated Relay I/O

A compact controller combining 100-240 VAC power, a 15 Kstep CPU, sixteen 24 VDC inputs and sixteen relay outputs for machine and panel control.
100-240 VAC
POWER
15 Kstep
PROGRAM
16 DI
24 VDC INPUTS
16 RO
RELAY OUTPUTS
◉ Sales manager: Miya zheng ✉ sales@amikon.cn ☎ 86-18020776792
⚙ CONTROL CORE
CPU and Built-In I/O at a Glance
POWER DOMAIN 100 to 240 VAC controller supply EXECUTION 83 ns per basic step
INPUT BANK 16 points, 24 VDC; 20.4 to 28.8 VDC range OUTPUT BANK 16 relay points; 2 A per point, 5 A per common
MEMORY 15 Kstep program capacity TIMEKEEPING Built-in real-time clock
➜ FAMILY ROUTE
Pick the Output Technology First
RELAY / 32 POINT TRANSISTOR / 32 POINT RELAY / 64 POINT TRANSISTOR / 64 POINT
MLC-DR32H

16 inputs + 16 relay outputs.

Use when: mixed AC/DC loads and contact isolation matter.
MLC-DN32H

16 inputs + 16 transistor outputs.

Use when: fast DC switching is the priority.
MLC-DR64H

32 inputs + 32 relay outputs.

Use when: the machine needs more relay points.
MLC-DN64H

32 inputs + 32 transistor outputs.

Use when: dense, fast DC control is required.
GLOBAL STOCK COORDINATION
Keep legacy and current automation systems moving.
◎ Quick Response Team
✓ Condition Check
12-month warranty. Raise any concern within seven days of receipt. Returned items must remain in original condition with a clear reason. Buyer-arranged freight applies.
◉ Sales manager: Miya zheng ✉ sales@amikon.cn ☎ 86-18020776792
▣ BUYER CHECKPOINTS
Five Practical Questions for MLC-DR32H
01 Can MLC-DR32H replace MLC-DN32H directly? No. Relay and transistor outputs differ in load type, switching speed, leakage and wiring.
02 Can all MLC-DR32H outputs switch 2 A together? Check the 2 A point rating, 5 A common limit, inrush, duty cycle and enclosure temperature.
03 What supply must be prepared for MLC-DR32H? Use 100 to 240 VAC with correct grounding, isolation and branch protection.
04 What should protect MLC-DR32H relay contacts? Apply suppression appropriate to inductive loads and confirm load inrush before selecting a contact.
05 What should be confirmed before MLC-DR32H purchase? Confirm supply, I/O count, relay load profile, common grouping, expansion need and software compatibility.
FINAL INQUIRY
Specify MLC-DR32H quantity and delivery country.
