ABB DSSB146 48980001-AP 18-32 V to 4.75-5.25 V DC/DC Converter

ABB DSSB146 48980001-AP 18-32 V to 4.75-5.25 V DC/DC Converter

ABB POWER CONVERSION COMPONENTS
DSSB146 48980001-AP
DC / DC CONVERTER
01 / PRODUCT ID
DSSB 146
ABB type designation
02 / CONVERSION
DC / DC
Direct-current conversion
03 / PRODUCT TYPE
Power Supply
Power supply component
SCAN TO CONNECT
✦ SALES SUPPORT Sales Manager
Miya Zheng
✉ Email: sales@amikon.cn ☎ WhatsApp: 86-18020776792
✦ International Delivery on the Day ✦ Quick Response Support ✦ Intercontinental Cooperation Network

  PRODUCT OVERVIEW

ABB LOW-VOLTAGE POWER PATH

DSSB146

48980001-AP

18-32 V to 4.75-5.25 V DC/DC converter

Replacement selection must preserve the complete ABB code, cabinet position, connector keying, supply path and downstream load conditions. A mechanically similar power unit is not automatically electrically compatible.

BUYER MATCH POINTS

01   Full DSSB146 48980001-AP marking

02   18-32 V input and 5 V load path

03   Connector, polarity and mounting

  01 / POWER RECORD

Buyer-critical operating profile


Complete marking DSSB146 48980001-AP
Role DC/DC converter power-supply unit
Input range 18 to 32 V DC
Output range 4.75 to 5.25 V DC
Conversion purpose Creates the low-voltage rail required by connected legacy control electronics
Buyer must match Polarity, connector pinout, mounting and downstream 5 V load
Before replacement Check the downstream rail for a short or excessive load
Condition inspection Power components, heat sinks, capacitors, connector pins and discoloration
  02 / PRE-POWER CHECK

Protect the replacement before energizing


01 Verify 18 to 32 V input Confirm supply level and polarity at the converter connector.
02 Inspect the 5 V load rail Check resistance and disconnect suspected downstream faults.
03 Match the connector pinout Compare keyed plugs, mounting and output wiring with the original unit.
04 Commission in stages Confirm 4.75 to 5.25 V before reconnecting the full downstream load.
  03 / SERIES PRIORITIES

Choose by electrical duty and cabinet role


DSSB146 48980001-AP Priority: 18 to 32 V DC input and regulated 4.75 to 5.25 V DC output. Choose when: the full DSSB146 48980001-AP marking, mounting and connector match.
DSSB145 48980001-AA Priority: a separate DSSB-series supply assembly. Choose when: the installed label specifically states DSSB145 and its electrical duty is confirmed.
DSSR170 48990001-PC Priority: 24 V-to-5 V regulation in the DSSR family. Choose when: the cabinet calls for DSSR170; do not infer interchangeability from voltage alone.
DSSB140 48980001-P Priority: battery-support duty rather than DC/DC conversion. Choose when: the existing assembly and cabinet circuit require the DSSB140 role.
  04 / GLOBAL SUPPORT

Broader expertise and faster global service





WHY AMIKON

Professional. Diverse. Responsive.

Expert support: experienced specialists help evaluate legacy requirements.

Broader reach: an international network supports scarce-part searches.

Faster action: prompt quotations and tracked delivery coordination help reduce downtime.

  05 / PURCHASE FAQ

Questions that protect the power system


Q1 / VOLTAGE

What voltages define ABB DSSB146 48980001-AP?

The converter accepts 18 to 32 V DC and provides a regulated 4.75 to 5.25 V DC output.

Q2 / SUBSTITUTE

Can ABB DSSB146 48980001-AP be replaced by DSSR170?

Both relate to low-voltage conversion, but mounting, connector and hardware details differ.

Q3 / PRE-CHECK

What should be checked before fitting ABB DSSB146 48980001-AP?

Confirm input voltage, polarity, output pinout, mounting and downstream load condition.

Q4 / SYMPTOMS

Which symptoms justify testing ABB DSSB146 48980001-AP?

Missing or unstable 5 V, repeated resets and heat-related shutdowns warrant power-path testing.

Q5 / LOAD RISK

Why test the downstream load before energizing ABB DSSB146 48980001-AP?

A short circuit or excessive load can immediately stress the replacement converter.
