ABB ACS550-01-023A-4 23 A Wall-Mounted Variable Frequency Drive

ABB ACS550-01-023A-4 23 A Wall-Mounted Variable Frequency Drive

ABB / LOW VOLTAGE AC DRIVES
ACS550-01-023A-4
GENERAL PURPOSE DRIVE
01 / OUTPUT CURRENT
23 A
Normal-use rating
02 / SUPPLY VOLTAGE
380–480 V
Three-phase AC
03 / MOTOR POWER
11 kW
Normal-use rating
✦ International Delivery on the Day ✦ Quick Response Support ✦ Intercontinental Cooperation Network
CONTACT US
✉ EMAIL US ☎ WHATSAPP
ABB GENERAL PURPOSE DRIVES
ACS550-01-023A-4
23 A Wall-Mounted Variable Frequency Drive
General-purpose motor control for pumps, fans, conveyors and process machinery in the 380 to 480 V class.
23 A
Nominal output current
380-480 V
Supply class
IP21 / R2
Enclosure and frame
PRODUCT OVERVIEW
General-purpose variable-speed drive
ABB ACS550-01-023A-4 is a wall-mounted general-purpose variable frequency drive rated 23 A in the 380 to 480 V class. This standard configuration uses an IP21 enclosure and R2 frame. Its control platform supports common industrial speed-control duties while the compact construction suits cabinet-mounted pump, fan, conveyor and process-machine applications.
TECHNICAL SPECIFICATIONS
Configuration and operating data
Drive family ABB ACS550
Type designation ACS550-01-023A-4
Product format Wall-mounted AC drive
Nominal output current 23 A
Voltage class 380 to 480 V AC
Standard enclosure IP21
Frame size R2
Heat dissipation 337 W
Required cooling airflow 88 cubic metres per hour
Typical acoustic level 66 dB
Maximum ambient without derating 40 C
Free space above and below 200 mm each
Optional output choke NOCH-0030-6X
Maximum motor cable without choke 200 m
Maximum motor cable with choke 250 m
System fit
Coordinate the drive with motor current, supply voltage, braking requirements, EMC environment, control signals and cabinet cooling. Maintain the specified airflow clearance.
Selection value
Select from motor rated current and overload duty, not only motor kW. Confirm IP rating, frame, control options and any fieldbus or braking accessories.
Application focus
Common uses include pumps, fans, conveyors, mixers and other variable-torque or constant-torque machinery within the drive rating.
AMIKON Global Supply Support
Twenty Years of Experience
Quality and Fast Response
Global automation supply, coordinated delivery and responsive quotation support for planned and urgent maintenance.
International Parts Network
Return support: Notify us within seven days if a concern is found. Goods must remain in original condition and include a clear return reason. Buyer-arranged return freight applies; refund or replacement review begins after receipt.
PROCUREMENT FAQ
Five checks before ordering ACS550-01-023A-4
01 Can ACS550-01-023A-4 be selected only from a 23 A motor nameplate value? Check motor current, overload duty, ambient temperature, switching frequency and installation altitude. Derating may require a larger drive.
02 Is ACS550-01-023A-4 supplied as IP21 or IP54? The base type is IP21. The IP54 variant carries an additional enclosure option, so confirm the complete label before replacement.
03 What cabinet cooling is needed for ACS550-01-023A-4? Plan for 337 W heat dissipation and approximately 88 cubic metres per hour of cooling airflow, with clear space above and below.
04 What must match when replacing ACS550-01-023A-4? Confirm voltage class, current, R2 frame, enclosure, control wiring, fieldbus options, braking arrangement and parameter backup.
05 What should be sent for an ACS550-01-023A-4 quotation? Provide the full type code, option suffixes, motor nameplate, supply voltage, load duty, enclosure need, quantity and delivery destination.
