The Bently Nevada 3500 Monitoring System is one of the most trusted and widely deployed condition monitoring platforms in the world. Engineered for critical rotating machinery, the 3500 Monitoring System offers unparalleled reliability, configurability, and diagnostic capabilities. This high-performance system is the flagship offering from Bently Nevada, a GE company renowned for decades of expertise in machinery protection and predictive maintenance technologies.

1. Comprehensive Machinery Protection

The 3500 Monitoring System provides real-time surveillance and protection for rotating assets such as turbines, compressors, pumps, and motors. It continuously monitors key parameters like:

Vibration/Thrust position/Speed/Temperature/Eccentricity/Phase

When configured with appropriate sensors and modules, the 3500 Monitoring System ensures early fault detection and immediate alarm escalation to protect against catastrophic failures.

2. Modular and Scalable Design

The 3500 Monitoring System is fully modular, consisting of a 19-inch rack that can accommodate a variety of plug-in monitoring modules. Its flexible configuration supports:

Up to 28 channels in a standard rack

Redundant power supply options

Optional Triple Modular Redundancy (TMR) for ultra-high availability

Users can tailor the system to match the complexity and criticality of each asset, ensuring optimal resource allocation.

3. Integration with System 1 Software

Bently Nevada’s System 1 software platform seamlessly integrates with the 3500 Monitoring System, enabling:

Advanced data visualization

Historical trend analysis

Remote diagnostics

Real-time alarm management

This software/hardware synergy allows maintenance teams to move from reactive to predictive strategies, extending equipment life and reducing unplanned outages.

4. Industry-Certified Reliability and Compliance

The 3500 Monitoring System meets stringent industry standards for safety and performance, including:

API 670 compliance

SIL 1/2 certifications for functional safety

CE, CSA, ATEX, and IECEx approvals

These certifications make it suitable for deployment in harsh and hazardous environments, such as oil & gas, power generation, and chemical processing plants.

5. Flexible Communication and Data Connectivity

The system offers a variety of communication protocols and interfaces, including:

Modbus (TCP/IP and Serial)

OPC DA and OPC UA

Ethernet and RS-232/RS-485 ports

This ensures the 3500 Monitoring System can integrate with almost any DCS, PLC, or SCADA system for centralized monitoring and control.

6. Long-Term Investment with Global Support

Bently Nevada’s global service network provides installation, commissioning, training, and lifecycle support for the 3500 Monitoring System. The platform’s backward compatibility and long-term product roadmap make it a solid investment for both greenfield installations and legacy system upgrades.

For more information about ABB or to request a quote, please contact Director_Miya

Recommended models:

BENTLY NEVADA 3500/94 145988-01 Display Router

BENTLY NEVADA 3500/94 145988-01 is part of the Bently Nevada 3500 Machinery Protection System series. It is a Main Module (VGA Display Module) that drives a touch-screen color VGA monitor, enabling operators to view real-time system data. The system includes both the 3500/94 VGA module and its I/O card, along with the external display monitor — connected via standard cabling up to approximately 8–10 m (26–33 ft) from the rack.

Bently Nevada 135489-02 I/O Module

The Bently Nevada 135489‑02 is a 4‑channel I/O module with built-in intrinsic safety barriers, tailored for the 3500/42M Seismic/Proximitor Monitor rack. It supports Prox/Accel and Velomitor sensors, enables explosion-safe installations, and offers reliable monitoring of critical rotating machinery in hazardous environments.

BENTLY NEVADA 3500/42M 176449-02 Seismic Monitor

The Bently Nevada 3500/42M 176449‑02 is a robust, four-channel Proximitor/Seismic Monitor module in the 3500 system, providing high-speed sampling, versatile signal conditioning, configurable alarms, and rugged design for industrial applications. Its API‑670 compliance and multi-sensor compatibility make it reliable for monitoring vital rotating equipment in demanding environments.
